1410271 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
CONN HEADER POWER 4POS EDGE MNT
| Part | Material Flammability Rating | Operating Temperature [Min] | Operating Temperature [Max] | Current Rating (Amps) | Voltage Rating | Contact Finish | Mounting Type | Termination | Contact Finish Thickness | Contact Finish Thickness | Contact Layout, Typical | Number of Positions | Connector Style | Number of Positions Loaded | Number of Rows | Connector Type | Color | Connector Usage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | UL94 V-0 | -55 C | 105 ░C | 20 A | 250 V | Gold | Board Edge Right Angle Through Hole | Press-Fit | 50 µin | 1.27 µm | 4 Power | 4 | Power | All | 1 | Header Male Blades | Black | |
 TE Connectivity AMP Connectors | UL94 V-0 | -55 C | 105 ░C | 20 A | 250 V | Gold | Board Edge Right Angle Through Hole | Press-Fit | 50 µin | 1.27 µm | 4 Power | 4 | Power | All | 1 | Header Male Blades | Black | |
 TE Connectivity AMP Connectors | UL94 V-0 | -55 C | 105 ░C | 20 A | 250 V | Gold | Board Edge Right Angle Through Hole | Press-Fit | 50 µin | 1.27 µm | 4 Power | 4 | Power | All | 1 | Plug Male Blades | Black | Daughtercard |
