333-052 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 52POS 0.156
| Part | Termination Rows [custom] | Material - Insulation | Number of Rows [custom] | Contact Type | Number of Positions/Bay/Row | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Read Out | Number of Positions | Contact Material | Color | Pitch | Pitch | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Termination | Gender | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Cantilever | 26 | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Gold | Dual | 52 | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Solder | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Through Hole | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 2 | Cantilever | 26 | Gold | Dual | 52 | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Through Hole | ||||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Cantilever | 26 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Gold | Dual | 52 | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Solder | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Through Hole | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Cantilever | 26 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Gold | Dual | 52 | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Solder | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Through Hole | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Cantilever | 26 | Gold | Dual | 52 | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Solder Eyelet(s) | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Board Edge Straddle Mount | Card Extender | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Cantilever | 26 | M3 Threaded Insert Top Mount Opening | Gold | Dual | 52 | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Wire Wrap | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Through Hole | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Cantilever | 26 | 4-40 Threaded Insert Top Mount Opening | Gold | Dual | 52 | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Solder | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Through Hole | |||
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Cantilever | 26 | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Gold | Dual | 52 | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Solder | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Board Edge Straddle Mount | Card Extender |
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Cantilever | 26 | 0.156 " | 3.96 mm | Gold | Dual | 52 | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Solder | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Board Edge Straddle Mount | Card Extender | |
 EDAC Inc. | 2 | Polyester Thermoplastic | 2 | Cantilever | 26 | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Gold | Dual | 52 | Copper Alloy | Green | 3.96 mm | 0.156 in | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Solder | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Board Edge Straddle Mount | Card Extender |
