SMC202 Series
Manufacturer: American Opto Plus LED
Beta
⌘K
DISP 14SEG 0.2DUAL RED 20SMD
| Part | Voltage - Forward (Vf) (Typ) | Current - Test | Millicandela Rating | Power Dissipation (Max) [Max] | Number of Characters | Color | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Wavelength - Peak | Package / Case | Display Type | Common Pin | Digit/Alpha Size | Digit/Alpha Size |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 American Opto Plus LED | 2 V | 20 mA | 12 mcd | 70 mW | 2 | Red | 0.394 in | 0.567 in | 0.118 in | 10 mm | 3 mm | 14.4 mm | 632 nm | 20-SMD No Lead | 7-Segment | Common Anode | 0.2 in | 5.08 mm |
