449-10 Series

Manufacturer: Mill-Max Manufacturing Corp.

Catalog

CONN HEADER SMD 62POS 2.54MM

Part	Contact Shape	Contact Length - Mating	Contact Length - Mating	Contact Type	Mounting Type	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Number of Rows [custom]	Contact Finish - Mating	Shrouding	Connector Type	Fastening Type	Pitch - Mating	Pitch - Mating	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Contact Finish Thickness - Post	Contact Finish Thickness - Post	Contact Finish - Post	Insulation Material	Insulation Color	Termination	Number of Positions Loaded	Number of Positions
Mill-Max Manufacturing Corp. 449-10-262-00-560000	Circular	3.45 mm	0.136 in	Male Pin	Surface Mount	0.25 µm	10 µin	2	Gold	Unshrouded	Header	Push-Pull	0.1 "	2.54 mm	0.1 in	2.54 mm	10 Áin	0.25 çm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT)	Black	Solder	All	62
Mill-Max Manufacturing Corp. 449-10-244-00-560000	Circular	3.45 mm	0.136 in	Male Pin	Surface Mount	0.25 µm	10 µin	2	Gold	Unshrouded	Header	Push-Pull	0.1 "	2.54 mm	0.1 in	2.54 mm	10 Áin	0.25 çm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT)	Black	Solder	All	44
Mill-Max Manufacturing Corp. 449-10-238-00-560000	Circular	3.45 mm	0.136 in	Male Pin	Surface Mount	0.25 µm	10 µin	2	Gold	Unshrouded	Header	Push-Pull	0.1 "	2.54 mm	0.1 in	2.54 mm	10 Áin	0.25 çm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT)	Black	Solder	All	38
Mill-Max Manufacturing Corp. 449-10-250-00-560000	Circular	3.45 mm	0.136 in	Male Pin	Surface Mount	0.25 µm	10 µin	2	Gold	Unshrouded	Header	Push-Pull	0.1 "	2.54 mm	0.1 in	2.54 mm	10 Áin	0.25 çm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT)	Black	Solder	All	50
Mill-Max Manufacturing Corp. 449-10-248-00-560000	Circular	3.45 mm	0.136 in	Male Pin	Surface Mount	0.25 µm	10 µin	2	Gold	Unshrouded	Header	Push-Pull	0.1 "	2.54 mm	0.1 in	2.54 mm	10 Áin	0.25 çm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT)	Black	Solder	All	48
Mill-Max Manufacturing Corp. 449-10-268-00-560000	Circular	3.45 mm	0.136 in	Male Pin	Surface Mount	0.25 µm	10 µin	2	Gold	Unshrouded	Header	Push-Pull	0.1 "	2.54 mm	0.1 in	2.54 mm	10 Áin	0.25 çm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT)	Black	Solder	All	68 positions
Mill-Max Manufacturing Corp. 449-10-246-00-560000	Circular	3.45 mm	0.136 in	Male Pin	Surface Mount	0.25 µm	10 µin	2	Gold	Unshrouded	Header	Push-Pull	0.1 "	2.54 mm	0.1 in	2.54 mm	10 Áin	0.25 çm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT)	Black	Solder	All	46
Mill-Max Manufacturing Corp. 449-10-230-00-560000	Circular	3.45 mm	0.136 in	Male Pin	Surface Mount	0.25 µm	10 µin	2	Gold	Unshrouded	Header	Push-Pull	0.1 "	2.54 mm	0.1 in	2.54 mm	10 Áin	0.25 çm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT)	Black	Solder	All	30
Mill-Max Manufacturing Corp. 449-10-254-00-560000	Circular	3.45 mm	0.136 in	Male Pin	Surface Mount	0.25 µm	10 µin	2	Gold	Unshrouded	Header	Push-Pull	0.1 "	2.54 mm	0.1 in	2.54 mm	10 Áin	0.25 çm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT)	Black	Solder	All	54
Mill-Max Manufacturing Corp. 449-10-222-00-560000	Circular	3.45 mm	0.136 in	Male Pin	Surface Mount	0.25 µm	10 µin	2	Gold	Unshrouded	Header	Push-Pull	0.1 "	2.54 mm	0.1 in	2.54 mm	10 Áin	0.25 çm	Gold	Polycyclohexylenedimethylene Terephthalate (PCT)	Black	Solder	All	22
