SCP Series

Manufacturer: SolaHD

Catalog

AC/DC DIN RAIL POWER SUPPLY (PSU), 2 OUTPUT, 30 W, 12 VDC, 1.2 A, -12 VDC, 1.2 A

Part	DC Voltage - Input (Max) [Max]	Standard Number	Applications	Approval Agency	Efficiency	Current - Output (Max)	Number of Outputs	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Power (Watts)	Operating Temperature [Min]	Operating Temperature [Max]	AC Voltage - Input [Max]	AC Voltage - Input [Min]	Voltage - Output 1	Input Type	Features	DC Voltage - Input (Min) [Min]	Voltage - Output 2	Voltage - Output 3	Current - Output (Max)	Current - Output (Max)
SolaHD SCP30D12B-UDN	375 V	60950-1	ITE (Commercial)	CE cURus	68 %	1.2 A	2	4.43 in	2.67 in	1.37 in	68 mm	35 mm	113 mm	29 W	-25 °C	65 °C	264 VAC	85 VAC	12 V	AC or DC	IP20 Universal Input	100 V	-12 V
SolaHD SCP30T512-UDN	375 V	60950-1	ITE (Commercial)	CE cURus	68 %	3 A	3	4.71 "	2.55 "	1.29 in	65 mm	33 mm	120 mm	29 W	-25 °C	65 °C	264 VAC	85 VAC	5 V	AC or DC	IP20 Universal Input	100 V	12 V	-12 V	600 mA	600 mA
SolaHD SCP30D15B-UDN	375 V	60950-1	ITE (Commercial)	CE cURus	68 %	1 A	2	4.43 in	2.67 in	1.37 in	68 mm	35 mm	113 mm	30 Watts	-25 °C	65 °C	264 VAC	85 VAC	15 V	AC or DC	IP20 Universal Input	100 V	-15 V
