D4G0611 Series
Basic / Snap Action Switches 3A, SPDT, 4.8 x 0.5 (0.187 x 0.020) QC, straight
Manufacturer: Electroswitch
Catalog
Basic / Snap Action Switches 3A, SPDT, 4.8 x 0.5 (0.187 x 0.020) QC, straight
Beta
⌘K
Basic / Snap Action Switches 3A, SPDT, 4.8 x 0.5 (0.187 x 0.020) QC, straight
Basic / Snap Action Switches 3A, SPDT, 4.8 x 0.5 (0.187 x 0.020) QC, straight
Basic / Snap Action Switches 3A, SPDT, 4.8 x 0.5 (0.187 x 0.020) QC, straight
| Part | Panel Cutout Dimensions [diameter] | Number of Positions [Max] | Number of Positions [Min] | Current Rating (Amps) | Number of Poles per Deck | Angle of Throw | Actuator Type | Actuator Type [diameter] | Actuator Length [x] | Index Stops | Contact Timing | Voltage Rating - AC | Depth Behind Panel [z] | Circuit per Deck | Contact Finish | Contact Material | Voltage Rating - DC | Termination Style | Number of Decks | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Electroswitch | 9.78 mm | 11 | 2 | 1.5 A 500 mA | 1 | 30 ° | Round | 0.25 in | 47.63 mm | Adjustable | Non-Shorting (BBM) | 115 V | 85.65 mm | SP11T | Silver | Brass | 28 V | Solder Lug | 6 | Panel Mount |
 Electroswitch | 9.78 mm | 11 | 2 | 1.5 A 500 mA | 1 | 30 ° | Round | 0.25 in | 47.63 mm | Adjustable | Shorting (MBB) | 115 V | 85.65 mm | SP11T | Silver | Brass | 28 V | Solder Lug | 6 | Panel Mount |
