1437671 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
TERM BLK 10P SIDE ENT 5.08MM PCB
| Part | Contact Material - Plating | Housing Material | Operating Temperature | Voltage | Current | Pitch | Pitch | Color | Mounting Type | Wire Termination | Features | Positions Per Level | Wire Gauge [Max] | Wire Gauge [Min] | Mating Orientation | Number of Levels |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Copper Alloy - Tin Plated | Polyester Thermoplastic | 130 °C | 150 V | 10 A | 5.08 mm | 0.2 in | Black | Through Hole | Leg Spring Push-In Spring | Lever Actuated | 10 | 22 AWG | 17.5 AWG | Horizontal with Board | 1 |
 TE Connectivity AMP Connectors | Copper Alloy - Tin Plated | Polyester Thermoplastic | 130 °C | 150 V | 10 A | 5.08 mm | 0.2 in | Black | Through Hole | Leg Spring Push-In Spring | Lever Actuated | 8 | 22 AWG | 17.5 AWG | Horizontal with Board | 1 |
 TE Connectivity AMP Connectors | Copper Alloy - Tin Plated | Polyester Thermoplastic | 130 °C | 150 V | 10 A | 5.08 mm | 0.2 in | Black | Through Hole | Leg Spring Push-In Spring | Lever Actuated | 3 | 22 AWG | 17.5 AWG | Horizontal with Board | 1 |
 TE Connectivity AMP Connectors | Copper Alloy - Tin Plated | Polyester Thermoplastic | 130 °C | 150 V | 10 A | 5.08 mm | 0.2 in | Black | Through Hole | Leg Spring Push-In Spring | Lever Actuated | 9 | 22 AWG | 17.5 AWG | Horizontal with Board | 1 |
 TE Connectivity AMP Connectors | Copper Alloy - Tin Plated | Polyester Thermoplastic | 130 °C | 150 V | 10 A | 5.08 mm | 0.2 in | Black | Through Hole | Leg Spring Push-In Spring | Lever Actuated | 12 | 22 AWG | 17.5 AWG | Horizontal with Board | 1 |
