B07D11 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
B07D111BC4-0202 = MS27247-2
| Part | Coil Resistance | Coil Voltage | Must Release Voltage | Operating Temperature [Min] | Operating Temperature [Max] | Operate Time | Termination Style | Seal Rating | Contact Rating (Current) | Mounting Type | Must Operate Voltage | Release Time | Contact Form | Coil Current | Coil Type | Relay Type | Contact Material | Qualification | Grade |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 300 Ohms | 26.5 VDC | 1.8 VDC | -65 ░C | 125 °C | 10 ms | PC Pin | Sealed - Hermetically | 10 A | Chassis Mount | 13 VDC | 10 ms | DPDT (2 Form C) | 88.3 mA | Non Latching | General Purpose | Silver Cadmium Oxide (AgCdO) | ||
 TE Connectivity AMP Connectors | 300 Ohms | 28 VDC | 1.6 VDC | -70 °C | 125 °C | 10 ms | Solder Hook | Sealed - Hermetically | 10 A | Chassis Mount | 13 VDC | 10 ms | DPDT (2 Form C) | 93.3 mA | Non Latching | General Purpose | Silver Cadmium Oxide (AgCdO) | MS27245 | Military |
 TE Connectivity AMP Connectors | 300 Ohms | 28 VDC | 1.6 VDC | -70 °C | 125 °C | 10 ms | Solder Hook | Sealed - Hermetically | 10 A | Chassis Mount | 13 VDC | 10 ms | DPDT (2 Form C) | 93.3 mA | Non Latching | General Purpose | Silver Cadmium Oxide (AgCdO) | MS27245 | Military |
