CPA500 Series
Manufacturer: Bel Fuse Inc.
Beta
⌘K
AC/DC CNVRTR 5V 3.3V +/-12V 500W
| Part | Minimum Load Required | Number of Outputs | Voltage - Output 4 | Current - Output 4 | Type | Voltage - Isolation | Mounting Type | Power (Watts) | Features | Voltage - Input [Max] | Voltage - Input [Min] | Voltage - Output 3 | Current - Output 2 | Applications | Voltage - Output 1 | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [z] | Efficiency | Voltage - Output 2 | Current - Output 1 | Current - Output 3 | Approval Agency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | 4 | -12 V | 4 A | Enclosed | 1.5 kV | Compact PCI® | 500 W | DC Input Capable Hot Swappable Load Sharing PFC Remote Sense | 264 VAC | 90 VAC | 12 V | 60 A | ITE (Commercial) | 5 V | 50 °C | -25 °C | 169.5 mm | 6.67 " | 10.31 " | 40.3 mm | 1.59 " | 261.9 mm | 84 % | 3.3 V | 50 A | 12 A | cCSAus CE cULus TUV |
