G-300 Series
Manufacturer: SWITCHCRAFT/CONXALL
Beta
⌘K
STANDARD CIRCULAR CONNECTOR RA PCB MOUNT 2P F WIDE BOARD LAYOUT
| Part | Current Rating (Amps) | Insert Material | Ingress Protection | Orientation | Color | Mounting Type | Material Flammability Rating | Connector Type | Primary Material | Contact Material | Termination | Number of Positions | Backshell Material, Plating | Applications | Fastening Type | Operating Temperature [Max] | Operating Temperature [Min] | Mounting Feature | Contact Finish - Mating | Shielding |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SWITCHCRAFT/CONXALL | Varies by Wire Gauge | Thermoplastic | Weathertight | Keyed | Black | Panel Mount Right Angle Through Hole | UL94 V-0 | Receptacle Female Sockets | Plastic | Copper Alloy | Circuit Board Solder | 2 | Nylon Polyamide (PA) | Automotive Communication Systems Instrumentation | Bayonet Lock | 85 °C | -40 C | Bulkhead - Front Side Nut | Gold | Unshielded |
 SWITCHCRAFT/CONXALL | Varies by Wire Gauge | Thermoplastic | Weathertight | Keyed | Black | Panel Mount Right Angle Through Hole | UL94 V-0 | Receptacle Male Pins | Plastic | Copper Alloy | Circuit Board Solder | 2 | Nylon Polyamide (PA) | Automotive Communication Systems Instrumentation | Bayonet Lock | 85 °C | -40 C | Bulkhead - Front Side Nut | Gold | Unshielded |
 SWITCHCRAFT/CONXALL | Varies by Wire Gauge | Thermoplastic | Weathertight | Keyed | Black | Panel Mount Right Angle Through Hole | UL94 V-0 | Receptacle Male Pins | Plastic | Copper Alloy | Circuit Board Solder | 6 | Nylon Polyamide (PA) | Automotive Communication Systems Instrumentation | Bayonet Lock | 85 °C | -40 C | Bulkhead - Front Side Nut | Gold | Unshielded |
