SPTAF Series
Manufacturer: Phoenix Contact
Beta
⌘K
FIXED TERMINAL BLOCKS SPTAF 1/ 6-3,5-EL
| Part | Housing Material | Positions Per Level | Pitch | Pitch | Wire Gauge [Max] | Wire Gauge [Min] | Number of Levels | Voltage | Mounting Type | Wire Termination | Features | Mating Orientation | Mating Orientation | Current | Color | Positions Per Level [custom] | Contact Material - Plating |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | Polyamide (PA) Nylon | 6 | 3.5 mm | 0.138 " | 24 AWG | 16 AWG | 1 | 300 VDC | Through Hole | Leg Spring Push-In Spring | Interlocking (Side) | 135 ° | 45 ° | 8 A | Green | ||
 Phoenix Contact | Polyamide (PA) Nylon | 11 | 5 mm | 0.197 in | 24 AWG | 16 AWG | 1 | 300 VDC | Through Hole | Leg Spring Push-In Spring | Interlocking (Side) | 135 ° | 45 ° | 8 A | Green | ||
 Phoenix Contact | Polyamide (PA) Nylon | 13 | 3.5 mm | 0.138 " | 24 AWG | 16 AWG | 1 | 300 VDC | Through Hole | Leg Spring Push-In Spring | Interlocking (Side) | 135 ° | 45 ° | 8 A | Green | ||
 Phoenix Contact | 11 | 5 mm | 0.197 in | 24 AWG | 16 AWG | 1 | 300 VDC | Through Hole | Leg Spring Push-In Spring | Interlocking (Side) | 135 ° | 45 ° | 8 A | Green | |||
 Phoenix Contact | Polyamide (PA) Nylon | 3 | 3.5 mm | 0.138 " | 24 AWG | 16 AWG | 1 | 300 VDC | Through Hole | Leg Spring Push-In Spring | Interlocking (Side) | 135 ° | 45 ° | 8 A | Green | ||
 Phoenix Contact | Polyamide (PA) Nylon | 3.5 mm | 0.138 " | 24 AWG | 16 AWG | 1 | 300 VDC | Through Hole | Leg Spring Push-In Spring | Interlocking (Side) | 135 ° | 45 ° | 8 A | Green | 7 | ||
 Phoenix Contact | Polyamide (PA) Nylon | 5 | 3.5 mm | 0.138 " | 24 AWG | 16 AWG | 1 | 300 VDC | Through Hole | Leg Spring Push-In Spring | Interlocking (Side) | 135 ° | 45 ° | 8 A | Green | Copper Alloy | |
 Phoenix Contact | Polyamide (PA) Nylon | 13 | 3.5 mm | 0.138 " | 24 AWG | 16 AWG | 1 | 300 VDC | Through Hole | Leg Spring Push-In Spring | Interlocking (Side) | 135 ° | 45 ° | 8 A | Green | Copper Alloy | |
 Phoenix Contact | Polyamide (PA) Nylon | 4 | 3.5 mm | 0.138 " | 24 AWG | 16 AWG | 1 | 300 VDC | Through Hole | Leg Spring Push-In Spring | Interlocking (Side) | 135 ° | 45 ° | 8 A | Green |
