895-018 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 18POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Flange Feature | Operating Temperature [Max] | Operating Temperature [Min] | Number of Positions/Bay/Row | Termination | Contact Finish | Card Type | Pitch | Pitch | Number of Positions | Gender | Read Out | Card Thickness [Max] | Card Thickness [Min] | Contact Material | Number of Rows [custom] | Color | Mounting Type | Termination Rows | Number of Rows | Number of Positions/Bay/Row [custom] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Cantilever | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | 125 °C | -40 C | 9 | Solder | Gold | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 18 | Female | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 2 | Black | Right Angle Through Hole | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | 18 | Female | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | Through Hole | 1 | 1 | 18 | 0.156 " | 3.96 mm | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Cantilever | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 125 °C | -40 C | 9 | Solder Eyelet(s) | Gold | Non Specified - Dual Edge | 0.1 " | 2.54 mm | 18 | Female | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | 2 | Black | Through Hole | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | 125 °C | -40 C | Solder | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | 18 | Female | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | Right Angle Through Hole | 1 | 1 | 18 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | 0.25 Ám | 10 Áin | Flush Mount Top Opening Unthreaded | 125 °C | -40 C | Solder | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | 18 | Female | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | Right Angle Through Hole | 1 | 1 | 18 | 0.128 " | 3.25 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | 0.25 Ám | 10 Áin | Floating Bobbin Flush Mount | 125 °C | -40 C | Solder | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | 18 | Female | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | Right Angle Through Hole | 1 | 1 | 18 | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | 0.25 Ám | 10 Áin | Floating Bobbin Top Mount Opening | 125 °C | -40 C | Wire Wrap | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | 18 | Female | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | Through Hole | 1 | 1 | 18 | 0.116 " | 2.95 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | 0.25 Ám | 10 Áin | M3 Threaded Insert Top Mount Opening | 125 °C | -40 C | Wire Wrap | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | 18 | Female | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | Through Hole | 1 | 1 | 18 | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Wire Wrap | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | 18 | Female | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | Through Hole | 1 | 1 | 18 | 0.156 " | 3.96 mm | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Cantilever | 0.25 Ám | 10 Áin | 125 °C | -40 C | Solder Eyelet(s) | Gold | Non Specified - Single Edge | 0.1 " | 2.54 mm | 18 | Female | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Copper Alloy | Black | Through Hole | 1 | 1 | 18 | 0.128 " | 3.25 mm |
