VCAS Series

Catalog

VARISTORS 13VAC 18VDC 0.1J 150 PF 25.5 V 42V

Part	Maximum DC Volts [Max]	Varistor Voltage (Min) [Min]	Current - Surge	Package / Case	Package / Case	Varistor Voltage (Typ)	Mounting Type	Qualification	Number of Circuits	Grade	Operating Temperature [Max]	Operating Temperature [Min]	Maximum AC Volts [Max]	Energy	Capacitance @ Frequency	Varistor Voltage (Max) [Max]
KYOCERA AVX VCAS060318A400DP	18 V	22.95 V	30 A	1608 Metric	0603	25.5 V	MLCV Surface Mount	AEC-Q200	1	Automotive	125 °C	-55 °C	13 V	0.1 J	150 pF
KYOCERA AVX VCAS120618E380RP	18 V	22.95 V	200 A		1206 (3216 Metric)	25.5 V	MLCV Surface Mount	AEC-Q200	1	Automotive	125 °C	-55 °C	13 V	0.5 J	1 kHz 930 pF
KYOCERA AVX VCAS060305A150DZ	5.6 V	6.8 V	30 A	1608 Metric	0603	8.5 V	MLCV Surface Mount	AEC-Q200	1	Automotive	125 °C	-55 °C	4 V	0.1 J	1 kHz 750 pF	10.2 V
KYOCERA AVX VCAS120618D400DZ	18 V	22.95 V	150 A		1206 (3216 Metric)	25.5 V	MLCV Surface Mount	AEC-Q200	1	Automotive	125 °C	-55 °C	13 V	0.4 J	900 pF
KYOCERA AVX VCAS121085S151RP
KYOCERA AVX VCAS080518A400RP	18 V	22.95 V	30 A		0805	25.5 V	MLCV Surface Mount	AEC-Q200	1	Automotive	125 °C	-55 °C	13 V	0.1 J	225 pF
KYOCERA AVX VCAS080505C150DZ	5.6 V	6.8 V	120 A		0805	8.5 V	MLCV Surface Mount	AEC-Q200	1	Automotive	125 °C	-55 °C	4 V	0.3 J	1 kHz 3000 pF	10.2 V
KYOCERA AVX VCAS080526C580DZ	26 V	31.05 V	100 A		0805	34.5 V	MLCV Surface Mount	AEC-Q200	1	Automotive	125 °C	-55 °C	18 V	0.3 J	1 kHz 250 pF	37.95 V
KYOCERA AVX VCAS080509A200TP	9 V	10.8 V	40 A		0805	12.7 V	MLCV Surface Mount	AEC-Q200	1	Automotive	125 °C	-55 °C	6.4 V	0.1 J	1 kHz 750 pF	14.61 V
KYOCERA AVX VCAS120614D300DP	14 V	16.28 V	150 A		1206 (3216 Metric)	18.5 V	MLCV Surface Mount	AEC-Q200	1	Automotive	125 °C	-55 °C	10 V	0.4 J	1050 pF	20.72 V
