LED Mounting Hardware AST W/OUT LED 1WAY
LED Mounting Hardware AST W/OUT LED 1WAY
LED Mounting Hardware AST W/OUT LED 1WAY
| Part | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Driver Circuitry | Termination | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Port Location | Technology | Operating Temperature [Max] | Operating Temperature [Min] | Voltage Range [Min] | Voltage Range [Max] | Voltage - Rated | Sound Pressure Level (SPL) | Input Type | Frequency | Mounting Type | Operating Mode | Current - Supply | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Ratings |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Mallory Sonalert Products Inc. | 0.394 in | 0.394 in | 10 mm | 10 mm | Externally Driven Transducer | Solder Pads | 0.126 in | 3.2 mm | Side | Magnetic | 85 °C | -20 ░C | 2.5 V | 4.5 V | 3 VDC | 87 dB | Peak-Peak Signal | 2.7 kHz | Surface Mount | Single Tone | 80 mA | |||
Mallory Sonalert Products Inc. | 0.197 " | 0.197 in | 5 mm | 5 mm | Externally Driven Transducer | Solder Pads | 0.075 " | 1.9 mm | Top | Magnetic | 70 °C | -20 ░C | 2 V | 4 V | 3 VDC | 75 dB | Peak-Peak Signal | 4 kHz | Surface Mount | Single Tone | 110 mA | |||
Mallory Sonalert Products Inc. | 0.669 " | 0.669 in | 17 mm | 17 mm | Externally Driven Transducer | Solder Pads | Top | Piezo | 70 °C | -30 ░C | 1 | 20 V | 5 V | 80 dB | Peak-Peak Signal | 4 kHz | Surface Mount | Single Tone | 2.5 mA | 0.209 " | 5.3 mm | |||
Mallory Sonalert Products Inc. | 0.335 in | 0.335 " | 8.5 mm | 8.5 mm | Externally Driven Transducer | Solder Pads | Side | Magnetic | 70 °C | -20 ░C | 2 V | 4 V | 3 VDC | 85 dB | Peak-Peak Signal | 2.731 kHz | Surface Mount | Single Tone | 80 mA | 0.118 " | 3 mm | |||
Mallory Sonalert Products Inc. | 0.496 in | 0.496 in | 12.6 mm | 12.6 mm | Externally Driven Transducer | Solder Pads | 0.283 in | 7.2 mm | Top | Magnetic | 85 °C | -40 C | 4 VDC | 7 V | 5 V | 87 dB | Peak-Peak Signal | 2.4 kHz | Surface Mount | Single Tone | 50 mA | Washable | ||
Mallory Sonalert Products Inc. | 0.496 in | 0.496 in | 12.6 mm | 12.6 mm | Externally Driven Transducer | Solder Pads | 0.283 in | 7.2 mm | Top | Magnetic | 85 °C | -40 C | 4 VDC | 7 V | 5 V | 87 dB | Peak-Peak Signal | 2.4 kHz | Surface Mount | Single Tone | 50 mA | Washable |
