LP02C31 Series
Manufacturer: LITTELFUSE
Beta
⌘K
SWITCH SLIDE SPDT 6A 125V
| Part | Electrical Life | Actuator Material | Voltage Rating - AC | Contact Material | Actuator Type | Features | Termination Style | Actuator Length [x] | Contact Timing | Voltage Rating - DC | Circuit | Mounting Type | Current Rating (Amps) | Operating Temperature [Min] | Operating Temperature [Max] | Contact Finish | Switch Function |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LITTELFUSE | 10000 Cycles | Acetal Glass Filled | 125 V | Copper | Snap on Cap | On-Off Marking on Housing | Solder Lug | 9.55 mm | Not Specified | 28 V | SPDT | Panel Mount Snap-In | 6 A | -30 ░C | 65 °C | Silver | On-On |
