W4S250 Series
Manufacturer: ebm-papst Inc.
Beta
⌘K
AC FAN AXIAL BALL BEARING 230V 512.06CFM/588.58CFM 58DB/62DB
| Part | Material - Frame | Material - Blade | Current Rating (Amps) | Size / Dimension | Size / Dimension [diameter] | Termination | Fan Type | RPM | Operating Temperature [Max] | Operating Temperature [Min] | Operating Temperature [Min] | Operating Temperature [Max] | Power (Watts) | Bearing Type | Voltage - Rated | Approval Agency | Static Pressure | Static Pressure | Ingress Protection | Width [y] | Features | Width [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ebm-papst Inc. | Plastic Coating Steel | Steel | 460 mA | Round | 320 mm | 3 Wire Leads with Splice Terminals | Tubeaxial | 1620 RPM | 50 °C | -25 °C | -25 °C | 50 °C | 75 W | Ball | 230 VAC | CE | 100 Pa | 0.401 in H2O | IP44 | 85 mm | Thermal Overload Protector (TOP) | |
 ebm-papst Inc. | Plastic Coating Steel | Steel | 1.12 A | Round | 320 mm | 3 Wire Leads with Splice Terminals | Tubeaxial | 1550 RPM | 40 °C | -25 °C | -25 °C | 40 °C | 80 W | Ball | 115 VAC | CE UL | IP44 | Thermal Overload Protector (TOP) | 88.9 mm |
