TSM-117 Series

Catalog

CONN HEADER SMD 34POS 2.54MM

...

Part	Connector Type	Contact Shape	Termination	Features	Contact Material	Contact Finish - Post	Contact Type	Insulation Height	Insulation Height	Material Flammability Rating	Number of Positions	Fastening Type	Pitch - Mating	Pitch - Mating	Number of Positions Loaded	Number of Rows	Shrouding	Insulation Color	Mounting Type	Style	Operating Temperature [Max]	Operating Temperature [Min]	Contact Length - Mating [x]	Contact Length - Mating [x]	Row Spacing - Mating [x]	Row Spacing - Mating [x]	Insulation Material	Contact Length - Mating	Contact Finish - Mating	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Contact Length - Mating
Samtec Inc. TSM-117-05-T-DV-A	Cuttable Header	Square	Solder	Board Guide	Phosphor Bronze	Tin	Male Pin	0.1 in	2.54 mm	UL94 V-0	34	Push-Pull	0.1 in	2.54 mm	All	2	Unshrouded	Black	Surface Mount	Board to Board Cable	105 ░C	-55 °C	1.9 mm	0.075 in	2.54 mm	0.1 in	Liquid Crystal Polymer (LCP)
Samtec Inc. TSM-117-01-L-DV-A-P	Cuttable Header	Square	Solder	Board Guide Pick and Place	Phosphor Bronze	Tin	Male Pin	0.1 in	2.54 mm	UL94 V-0	34	Push-Pull	0.1 in	2.54 mm	All	2	Unshrouded	Black	Surface Mount	Board to Board Cable	125 °C	-55 °C		0.23 in	2.54 mm	0.1 in	Liquid Crystal Polymer (LCP)	5.84 mm	Gold	10 çin	0.25 çm
Samtec Inc. TSM-117-02-S-SV
Samtec Inc. TSM-117-01-L-EM	Header	Square	Solder		Phosphor Bronze	Tin	Male Pin			UL94 V-0	34	Push-Pull	0.1 in	2.54 mm	All	2	Unshrouded	Black	Board Edge Straddle Mount	Board to Board Cable	125 °C	-55 °C		0.23 in	2.54 mm	0.1 in	Liquid Crystal Polymer (LCP)	5.84 mm	Gold	10 çin	0.25 çm
Samtec Inc. TSM-117-01-L-DH-A-P	Header	Square	Solder	Board Guide Pick and Place	Phosphor Bronze	Tin	Male Pin	0.24 in	6.1 mm	UL94 V-0	34	Push-Pull	0.1 in	2.54 mm	All	2	Unshrouded	Black	Surface Mount Right Angle	Board to Board Cable	125 °C	-55 °C		0.23 in	2.54 mm	0.1 in	Liquid Crystal Polymer (LCP)	5.84 mm	Gold	10 çin	0.25 çm
Samtec Inc. TSM-117-01-L-DH	Header	Square	Solder		Phosphor Bronze	Tin	Male Pin	0.24 in	6.1 mm	UL94 V-0	34	Push-Pull	0.1 in	2.54 mm	All	2	Unshrouded	Black	Surface Mount Right Angle	Board to Board Cable	125 °C	-55 °C		0.23 in	2.54 mm	0.1 in	Liquid Crystal Polymer (LCP)	5.84 mm	Gold	10 çin	0.25 çm
Samtec Inc. TSM-117-03-S-SV	Cuttable Header	Square	Solder		Phosphor Bronze	Tin	Male Pin	0.1 in	2.54 mm	UL94 V-0		Push-Pull	0.1 in	2.54 mm	All	1	Unshrouded	Black	Surface Mount	Board to Board Cable	125 °C	-55 °C					Liquid Crystal Polymer (LCP)	10.67 mm	Gold	30 Áin	0.76 Ám	0.42 in
Samtec Inc. TSM-117-04-F-SH-A	Header	Square	Solder	Board Guide	Phosphor Bronze	Tin	Male Pin	0.12 in	3.05 mm	UL94 V-0		Push-Pull	0.1 in	2.54 mm	All	1	Unshrouded	Black	Surface Mount Right Angle	Board to Board Cable	125 °C	-55 °C					Liquid Crystal Polymer (LCP)	3.05 mm	Gold	3 µin	0.076 µm	0.12 in
Samtec Inc. TSM-117-01-TL-DV	Cuttable Header	Square	Solder		Phosphor Bronze	Tin	Male Pin	0.1 in	2.54 mm	UL94 V-0	34	Push-Pull	0.1 in	2.54 mm	All	2	Unshrouded	Black	Surface Mount	Board to Board Cable	105 ░C	-55 °C		0.23 in	2.54 mm	0.1 in	Liquid Crystal Polymer (LCP)	5.84 mm
Samtec Inc. TSM-117-01-L-DV-LC-P	Cuttable Header	Square	Solder	Board Lock Pick and Place	Phosphor Bronze	Tin	Male Pin	0.1 in	2.54 mm	UL94 V-0	34	Push-Pull	0.1 in	2.54 mm	All	2	Unshrouded	Black	Surface Mount	Board to Board Cable	125 °C	-55 °C		0.23 in	2.54 mm	0.1 in	Liquid Crystal Polymer (LCP)	5.84 mm	Gold	10 çin	0.25 çm
