SDS155 Series
Manufacturer: Sullins Connector Solutions
Beta
⌘K
CONN D-SUB RCPT 9POS VERT SLDR
| Part | Color | Contact Material | Dielectric Material | Voltage Rating | Operating Temperature [Min] | Operating Temperature [Max] | Contact Form | Connector Type | Number of Positions | Number of Rows [custom] | Contact Finish | Flange Feature | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Material Flammability Rating | Termination | Connector Style | Current Rating (Amps) | Contact Type | Contact Finish Thickness | Mounting Type | Shell Size, Connector Layout | Shell Size, Connector Layout [x] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sullins Connector Solutions | Black | Brass | Polybutylene Terephthalate (PBT) Glass Filled | 250 V | -55 C | 105 ░C | Stamped | Receptacle Female Sockets | 9 | 2 | Gold | Housing/Shell (Unthreaded) | 1 | DE E | UL94 V-0 | Solder | D-Sub | 3 A | Signal | Flash | Through Hole | |||
Sullins Connector Solutions | Black | Brass | Polybutylene Terephthalate (PBT) Glass Filled | 250 V | -55 C | 105 ░C | Stamped | Receptacle Female Sockets | 25 | 2 | Gold | Housing/Shell (Unthreaded) | UL94 V-0 | Solder | D-Sub | 3 A | Signal | Flash | Through Hole | B DB | 3 | |||
 Sullins Connector Solutions | Black | Brass | Polybutylene Terephthalate (PBT) Glass Filled | 250 V | -55 C | 105 ░C | Stamped | Receptacle Female Sockets | 25 | 2 | Gold | Board Side (4-40) | UL94 V-0 | Solder | D-Sub | 3 A | Signal | Flash | Through Hole | B DB | 3 | Board Lock |
