MBC40 Series
Manufacturer: Bel Fuse Inc.
Beta
⌘K
AC/DC CONVERTER 12V 40W
| Part | Minimum Load Required | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Efficiency | Features | Number of Outputs | Voltage - Output 1 | Applications | Mounting Type | Type | Operating Temperature [Max] | Operating Temperature [Min] | Voltage - Input [Max] | Voltage - Input [Min] | Power (Watts) | Current - Output 1 | Voltage - Isolation | Current - Output 2 | Voltage - Output 2 | Voltage - Output 3 | Current - Output 3 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bel Fuse Inc. | 1.2 " | 50.8 mm | 101.6 mm | 2 in | 4 " | 30.5 mm | 85 % | Adjustable Output Remote Sense Standby Output Universal Input | 1 | 12 V | Medical | Chassis Mount | Open Frame | 70 °C | -20 °C | 264 VAC | 90 VAC | 40 W | 3.5 A | 4.242 kV | |||||
 Bel Fuse Inc. | 1.2 " | 50.8 mm | 101.6 mm | 2 in | 4 " | 30.5 mm | 85 % | Adjustable Output Remote Sense Standby Output Universal Input | 3 | 5.2 V | Medical | Chassis Mount | Open Frame | 70 °C | -20 °C | 264 VAC | 90 VAC | 40 W | 6 A | 4.242 kV | 1.5 A | 14.6 V | -14.8 V | 500 mA | |
 Bel Fuse Inc. | 1.2 " | 50.8 mm | 101.6 mm | 2 in | 4 " | 30.5 mm | 85 % | Adjustable Output Remote Sense Standby Output Universal Input | 1 | 5.1 V | Medical | Chassis Mount | Open Frame | 70 °C | -20 °C | 264 VAC | 90 VAC | 40 W | 8 A | 4.242 kV | |||||
 Bel Fuse Inc. | 1.2 " | 50.8 mm | 101.6 mm | 2 in | 4 " | 30.5 mm | 85 % | Adjustable Output Remote Sense Standby Output Universal Input | 3 | 5.2 V | Medical | Chassis Mount | Open Frame | 70 °C | -20 °C | 264 VAC | 90 VAC | 40 W | 6 A | 4.242 kV | 1 A | 24 V | -12.8 V | 500 mA | |
Bel Fuse Inc. | 1.2 " | 50.8 mm | 101.6 mm | 2 in | 4 " | 30.5 mm | 85 % | Adjustable Output Remote Sense Standby Output Universal Input | 1 | 5.1 V | Medical | Chassis Mount | Open Frame | 70 °C | -20 °C | 264 VAC | 90 VAC | 40 W | 8 A | 4.242 kV | |||||
Bel Fuse Inc. | 1.2 " | 50.8 mm | 101.6 mm | 2 in | 4 " | 30.5 mm | 85 % | Adjustable Output Remote Sense Standby Output Universal Input | 3 | 5.2 V | Medical | Chassis Mount | Open Frame | 70 °C | -20 °C | 264 VAC | 90 VAC | 40 W | 6 A | 4.242 kV | 1.5 A | 14.6 V | -14.8 V | 500 mA | |
 Bel Fuse Inc. | 1.2 " | 50.8 mm | 101.6 mm | 2 in | 4 " | 30.5 mm | 85 % | Adjustable Output Remote Sense Standby Output Universal Input | 1 | 15 V | Medical | Chassis Mount | Open Frame | 70 °C | -20 °C | 264 VAC | 90 VAC | 40 W | 2.7 A | 4.242 kV | |||||
 Bel Fuse Inc. | 1.2 " | 50.8 mm | 101.6 mm | 2 in | 4 " | 30.5 mm | 85 % | Adjustable Output Remote Sense Standby Output Universal Input | 1 | 48 V | Medical | Chassis Mount | Open Frame | 70 °C | -20 °C | 264 VAC | 90 VAC | 40 W | 830 mA | 4.242 kV | |||||
 Bel Fuse Inc. | 1.2 " | 50.8 mm | 101.6 mm | 2 in | 4 " | 30.5 mm | 85 % | Adjustable Output Remote Sense Standby Output Universal Input | 1 | 24 V | Medical | Chassis Mount | Open Frame | 70 °C | -20 °C | 264 VAC | 90 VAC | 40 W | 1.7 A | 4.242 kV | |||||
Bel Fuse Inc. | 1.2 " | 50.8 mm | 101.6 mm | 2 in | 4 " | 30.5 mm | 85 % | Adjustable Output Remote Sense Standby Output Universal Input | 1 | 15 V | Medical | Chassis Mount | Open Frame | 70 °C | -20 °C | 264 VAC | 90 VAC | 40 W | 2.7 A | 4.242 kV |
