CB6M Series

Catalog

CONN PLUG 4POS INLINE PIN

Part	Shielding	Current Rating (Amps)	Contact Finish - Mating	Shell Size - Insert	Shell Finish	Ingress Protection	Color	Mounting Type	Fastening Type	Number of Positions	Connector Type	Orientation	Qualification	Shell Material	Primary Material	Voltage Rating	Operating Temperature [Min]	Operating Temperature [Max]	Termination	Contact Shape	Insert Material	Note	Contact Size	Type	Housing Color	Contact Type	Features	Shell Size - Insert [Max]	Shell Size - Insert [Min]	Orientation [x]
ITT Cannon, LLC CB6M18-4PS	Shielded	22 A	Silver	18-4	Olive Drab Cadmium	IP67 - Dust Tight Waterproof	Olive Drab	Free Hanging (In-Line)	Reverse Bayonet Lock	4	Plug Male Pins	N (Normal)	MIL-DTL-5015	Aluminum Alloy	Metal	50 V	-55 C	125 °C
ITT Cannon, LLC CB6M18-1PSAU	Shielded	22 A	Gold	18-1	Olive Drab Cadmium	IP67 - Dust Tight Waterproof	Olive Drab	Free Hanging (In-Line)	Reverse Bayonet Lock	10	Plug Male Pins	N (Normal)	MIL-DTL-5015	Aluminum Alloy	Metal	50 V	-55 C	125 °C
ITT Cannon, LLC CB6M14S-6PCAU	Shielded	22 A	Gold	14S-6	Olive Drab Cadmium	IP67 - Dust Tight Waterproof	Olive Drab	Free Hanging (In-Line)	Reverse Bayonet Lock	6	Plug Male Pins	N (Normal)	MIL-DTL-5015	Aluminum Alloy	Metal	50 V	-55 C	125 °C	Crimp
ITT Cannon, LLC CB6M14S-5P0	Shielded			14S-5	Chromate over Cadmium	IP67 - Dust Tight Waterproof		Free Hanging (In-Line)	Reverse Bayonet Lock	5	Plug Housing	N (Normal)	MIL-DTL-5015	Aluminum Alloy			-55 C	125 °C		Circular	Polychloroprene	Contacts Not Included	16S	For Male Pins	Olive Drab	Crimp Solder Solder Cup	Backshell Coupling Nut
ITT Cannon, LLC CB6M18-12PC	Shielded	22 A	Silver		Olive Drab Cadmium	IP67 - Dust Tight Waterproof	Olive Drab	Free Hanging (In-Line)	Reverse Bayonet Lock	6	Plug Male Pins	N (Normal)	MIL-DTL-5015	Aluminum Alloy	Metal	50 V	-55 C	125 °C	Crimp									12	18
ITT Cannon, LLC CB6M14S-6PS	Shielded	22 A	Silver	14S-6	Olive Drab Cadmium	IP67 - Dust Tight Waterproof	Olive Drab	Free Hanging (In-Line)	Reverse Bayonet Lock	6	Plug Male Pins	N (Normal)	MIL-DTL-5015	Aluminum Alloy	Metal	50 V	-55 C	125 °C
ITT Cannon, LLC CB6M14S-2PXS	Shielded	22 A	Silver	14S-2	Olive Drab Cadmium	IP67 - Dust Tight Waterproof	Olive Drab	Free Hanging (In-Line)	Reverse Bayonet Lock	4	Plug Male Pins		MIL-DTL-5015	Aluminum Alloy	Metal	50 V	-55 C	125 °C												X
ITT Cannon, LLC CB6M14S-2PS	Shielded	22 A	Silver	14S-2	Olive Drab Cadmium	IP67 - Dust Tight Waterproof	Olive Drab	Free Hanging (In-Line)	Reverse Bayonet Lock	4	Plug Male Pins	N (Normal)	MIL-DTL-5015	Aluminum Alloy	Metal	50 V	-55 C	125 °C
ITT Cannon, LLC CB6M18-1PS	Shielded	22 A	Silver	18-1	Olive Drab Cadmium	IP67 - Dust Tight Waterproof	Olive Drab	Free Hanging (In-Line)	Reverse Bayonet Lock	10	Plug Male Pins	N (Normal)	MIL-DTL-5015	Aluminum Alloy	Metal	50 V	-55 C	125 °C
ITT Cannon, LLC CB6M18-11PSAU	Shielded	41 A	Gold		Olive Drab Cadmium	IP67 - Dust Tight Waterproof	Olive Drab	Free Hanging (In-Line)	Reverse Bayonet Lock	5	Plug Male Pins	N (Normal)	MIL-DTL-5015	Aluminum Alloy	Metal	50 V	-55 C	125 °C										11	18
