MAX40024 Series

Low-Noise, Low-Power, Low-Bias-Current Amplifiers

Manufacturer: Analog Devices Inc./Maxim Integrated

Catalog

Low-Noise, Low-Power, Low-Bias-Current Amplifiers

Part	Voltage - Supply Span (Min) [Min]	Current - Supply	Supplier Device Package	Operating Temperature [Max]	Operating Temperature [Min]	Slew Rate	Voltage - Input Offset	Number of Circuits	Voltage - Supply Span (Max) [Max]	Package / Case	Output Type	Gain Bandwidth Product	Current - Input Bias	Amplifier Type	Current - Output / Channel	Mounting Type
Analog Devices Inc./Maxim Integrated MAX40024ANL+	1.6 V	17 µA	9-WLP (1.23x1.23)	125 °C	-40 C	20 V/ms	100 çV	2	3.6 V	9-XFBGA WLBGA	Rail-to-Rail	80 kHz	0.1 pA	General Purpose	10 mA	Surface Mount
Analog Devices Inc./Maxim Integrated MAX40024ANL+T	1.6 V	17 µA	9-WLP (1.23x1.23)	125 °C	-40 °C	20 V/ms	100 çV	2	3.6 V	9-XFBGA WLBGA	Rail-to-Rail	80 kHz	0.1 pA	General Purpose	10 mA	Surface Mount

Catalog

Low-Noise, Low-Power, Low-Bias-Current Amplifiers

Description

The MAX40023/MAX40024 are single and dual amplifiers optimized for power-sensitive applications that require low noise and very low-leakage input current (bias current).The MAX40023/MAX40024 amplifiers consume less than 17µA (typ) of supply current per channel, but also feature incredibly low noise as low as 32nV/√Hz. The input bias current is <1pA at room temperature.These amplifiers are available in a space-saving, 6-bump wafer-level package (WLP) with a 0.4mm bump pitch (single), 9-bump WLP (dual), 6-pin SOT23 (single), and 10-pin TDFN (dual). They are designed for use as a sensor interface in wearable medical and industrial sensor applications.The MAX40023/MAX40024 amplifiers operate from a 1.6V to 3.6V power supply voltage and arespecified over the -40°C to +125°C operating temperature range.ApplicationsBattery-Powered DevicesIndustrial SensorsWearable Medical
