Minibend Series

Catalog

CABLE ASSY, SMA PLUG-PLUG, 2.5" ROHS COMPLIANT: YES

Part	Operating Temperature [Min]	Operating Temperature [Max]	Cable Type	Cable Type	Frequency - Max [Max]	2nd Connector Mounting Type	Length	Length	Style	Color	1st Connector Mounting Type	2nd Connector	1st Contact Gender	1st Connector	2nd Contact Gender	Overall Impedance	1st Connector	2nd Connector	Style [Max]	Style [Min]	Features	Length [x]	Length [x]
Huber+Suhner, Inc. MINIBEND R-2.5HT	-55 C	125 °C	0.086 in	Semi-Rigid Cable	24 GHz	Free Hanging (In-Line)	14 in	355.6 mm	SMA to SMA	Blue	Free Hanging (In-Line)	SMA Plug	Male	SMA Plug	Male	50 Ohms
Huber+Suhner, Inc. MINIBEND KR-11	-55 C	105 ░C	0.086 in	Semi-Rigid Cable	40 GHz	Free Hanging (In-Line)	11 in	279.4 mm		Blue	Free Hanging (In-Line)		Male		Male	50 Ohms	2.92 mm	2.92 mm	2.92 mm	2.92 mm
Huber+Suhner, Inc. MINIBEND L2SR-16
Huber+Suhner, Inc. MINIBEND LSR-3	-55 C	125 °C	0.086 in	Semi-Rigid Cable	18 GHz	Free Hanging (In-Line)	3 in	76.2 mm	SMA to SMP	Silver	Free Hanging (In-Line)	SMA Jack	Male	SMA Plug	Female	50 Ohms
Huber+Suhner, Inc. MINIBEND-3	-55 C	200 °C	0.086 in	Semi-Rigid Cable	24 GHz	Free Hanging (In-Line)	3 in	76.2 mm	SMA to SMA	Blue	Free Hanging (In-Line)	SMA Plug	Male	SMA Plug	Male	50 Ohms					Shielded
Huber+Suhner, Inc. MINIBEND LR-8HT	-55 C	125 °C	0.086 in	Semi-Rigid Cable	26.5 GHz	Free Hanging (In-Line)	8 in	203.2 mm	SMA to SMA	Silver	Free Hanging (In-Line)	SMA Plug	Male	SMA Plug	Male	50 Ohms
Huber+Suhner, Inc. MINIBEND SR-6	-55 C	125 °C	0.086 in	Semi-Rigid Cable	20 GHz	Free Hanging (In-Line)			SMA to SMB	Blue	Free Hanging (In-Line)	SMB Jack	Male	SMA Plug	Female	50 Ohms						152.4 mm	6 "
Huber+Suhner, Inc. Minibend R-12	-55 C	200 °C	0.086 in	Semi-Rigid Cable	24 GHz	Free Hanging (In-Line)			SMA to SMA	Blue	Free Hanging (In-Line)	SMA Plug	Male	SMA Plug	Male	50 Ohms					Shielded	304.8 mm	12 in
Huber+Suhner, Inc. Minibend KR-2.5	-55 C	105 ░C	0.086 in	Semi-Rigid Cable	40 GHz	Free Hanging (In-Line)				Blue	Free Hanging (In-Line)		Male		Male	50 Ohms	2.92 mm	2.92 mm	2.92 mm	2.92 mm		63.5 mm	2.5 in
Huber+Suhner, Inc. Minibend LR-14	-55 C	125 °C	0.086 in	Semi-Rigid Cable	26.5 GHz	Free Hanging (In-Line)	14 in	355.6 mm	SMA to SMA	Silver	Free Hanging (In-Line)	SMA Plug	Male	SMA Plug	Male	50 Ohms
