1814655 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN SOCKET SIP 20POS GOLD
| Part | Pitch - Mating | Pitch - Mating | Material Flammability Rating | Mounting Type | Housing Material | Contact Finish - Post | Termination Post Length [x] | Termination Post Length [x] | Contact Finish Thickness - Mating | Termination | Contact Resistance | Contact Material - Post [custom] | Type | Number of Positions or Pins (Grid) [custom] | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material - Mating | Contact Finish - Mating | Features | Pitch - Post | Pitch - Post | Current Rating (Amps) | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Post | Number of Positions or Pins (Grid) | Number of Positions or Pins (Grid) [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | 0.1 in | 2.54 mm | UL94 V-0 | Through Hole | Polyester Thermoplastic | Tin | 2.9 mm | 0.114 in | Flash | Solder | 10 mOhm | Brass | SIP | 20 | 196.9 µin | 5 µm | -55 °C | 125 °C | Beryllium Copper | Gold | Closed Frame | 2.54 mm | 0.1 in | ||||||
TE Connectivity Raychem Cable Protection | 0.1 in | 2.54 mm | UL94 V-0 | Through Hole | Polyester Thermoplastic | Gold | 2.9 mm | 0.114 in | Solder | 10 mOhm | Brass | SIP | 20 | 0.75 µm | -55 °C | 125 °C | Beryllium Copper | Gold | Closed Frame | 2.54 mm | 0.1 in | 1 A | 29.5 Áin | 0.75 Ám | 29.5 µin | ||||
TE Connectivity Raychem Cable Protection | 0.1 in | 2.54 mm | UL94 V-0 | Through Hole | Polyester Thermoplastic | Gold | 2.9 mm | 0.114 in | Solder | 10 mOhm | Brass | SIP | 0.75 µm | -55 °C | 125 °C | Beryllium Copper | Gold | Closed Frame | 2.54 mm | 0.1 in | 1 A | 29.5 Áin | 0.75 Ám | 29.5 µin | 4 | 1 x 4 | |||
 TE Connectivity Raychem Cable Protection | 0.1 in | 2.54 mm | UL94 V-0 | Through Hole | Polyester Thermoplastic | Gold | 2.9 mm | 0.114 in | Solder | 10 mOhm | Brass | SIP | 0.75 µm | -55 °C | 125 °C | Beryllium Copper | Gold | Closed Frame | 2.54 mm | 0.1 in | 1 A | 29.5 Áin | 0.75 Ám | 29.5 µin | 10 | ||||
 TE Connectivity Raychem Cable Protection | 0.1 in | 2.54 mm | UL94 V-0 | Through Hole | Polyester Thermoplastic | Tin | 2.9 mm | 0.114 in | Flash | Solder | 10 mOhm | Brass | SIP | 196.9 µin | 5 µm | -55 °C | 125 °C | Beryllium Copper | Gold | Closed Frame | 2.54 mm | 0.1 in | 16 |
