TG2016SBN Series

Manufacturer: EPSON

Catalog

TCXO OSCILLATORS 38.4000MHZ +/-.5PPM 2.6-3.3V -40C +85C

Part	Operating Temperature [Max]	Operating Temperature [Min]	Base Resonator [custom]	Supplier Device Package [y]	Supplier Device Package [x]	Supplier Device Package [custom]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Frequency Stability	Type	Height - Seated (Max) [Max]	Height - Seated (Max)	Voltage - Supply [Min]	Voltage - Supply [Max]	Package / Case	Output	Frequency	Mounting Type	Current - Supply (Max) [Max]
EPSON TG2016SBN 38.4000M-PCGNDM3	85 °C	-40 C	Crystal	1.6	2	4-SMD	1.6 mm	0.079 in	0.063 "	2 mm	500 ppb	VCTCXO	0.031 in	0.8 mm	2.6 V	3.3 V	4-SMD No Lead	Sine Wave	38.4 MHz	Surface Mount	1.8 mA
EPSON TG2016SBN 32.0000M-MCGNEM5	85 °C	-40 C	Crystal	1.6	2	4-SMD	1.6 mm	0.079 in	0.063 "	2 mm	500 ppb	VCTCXO	0.031 in	0.8 mm	2.8 V	3.3 V	4-SMD No Lead	Sine Wave	32 MHz	Surface Mount	1.5 mA
EPSON TG2016SBN 39.0000M-KCGNCM0	85 °C	-40 C	Crystal	1.6	2	4-SMD	1.6 mm	0.079 in	0.063 "	2 mm	500 ppb	VCTCXO	0.031 in	0.8 mm	2.5 V	3.3 V	4-SMD No Lead	Sine Wave	39 MHz	Surface Mount	1.8 mA
EPSON TG2016SBN 27.0000M-PCGNDM5	85 °C	-40 C	Crystal	1.6	2	4-SMD	1.6 mm	0.079 in	0.063 "	2 mm	500 ppb	VCTCXO	0.031 in	0.8 mm	2.6 V	3.3 V	4-SMD No Lead	Sine Wave	27 MHz	Surface Mount	1.5 mA
EPSON TG2016SBN 19.2000M-PCGNDM5	85 °C	-40 C	Crystal	1.6	2	4-SMD	1.6 mm	0.079 in	0.063 "	2 mm	500 ppb	VCTCXO	0.031 in	0.8 mm	2.6 V	3.3 V	4-SMD No Lead	Sine Wave	19.2 MHz	Surface Mount	1.4 mA
EPSON TG2016SBN 38.4000M-TCGNNM0	85 °C	-40 C	Crystal	1.6	2	4-SMD	1.6 mm	0.079 in	0.063 "	2 mm	500 ppb	TCXO	0.031 in	0.8 mm	1.8 V	3.3 V	4-SMD No Lead	Sine Wave	38.4 MHz	Surface Mount	1.8 mA
EPSON TG2016SBN 16.3680M-KCGNCM0	85 °C	-40 C	Crystal	1.6	2	4-SMD	1.6 mm	0.079 in	0.063 "	2 mm	500 ppb	VCTCXO	0.031 in	0.8 mm	2.5 V	3.3 V	4-SMD No Lead	Sine Wave	16.368 MHz	Surface Mount	1.4 mA
EPSON TG2016SBN 28.9740M-PCGNDM3	85 °C	-40 C	Crystal	1.6	2	4-SMD	1.6 mm	0.079 in	0.063 "	2 mm	500 ppb	VCTCXO	0.031 in	0.8 mm	2.6 V	3.3 V	4-SMD No Lead	Sine Wave	28.974 MHz	Surface Mount	1.5 mA
EPSON TG2016SBN 26.0000M-KCGNCM5	85 °C	-40 C	Crystal	1.6	2	4-SMD	1.6 mm	0.079 in	0.063 "	2 mm	500 ppb	VCTCXO	0.031 in	0.8 mm	2.5 V	3.3 V	4-SMD No Lead	Sine Wave	26 MHz	Surface Mount	1.4 mA
EPSON TG2016SBN 16.3840M-MCGNEM0	85 °C	-40 C	Crystal	1.6	2	4-SMD	1.6 mm	0.079 in	0.063 "	2 mm	500 ppb	VCTCXO	0.031 in	0.8 mm	2.8 V	3.3 V	4-SMD No Lead	Sine Wave	16.384 MHz	Surface Mount	1.4 mA
