SI8651 Series

Catalog

DGTL ISOLTR 3.75KV 5CH GP 16SOIC

Part	Pulse Width Distortion (Max) [Max]	Grade	Package / Case	Package / Case	Voltage - Isolation	Inputs - Side 1/Side 2 [custom]	Inputs - Side 1/Side 2 [custom]	Type	Qualification	Channel Type	Number of Channels [custom]	Propagation Delay tpLH / tpHL (Max)	Voltage - Supply [Min]	Voltage - Supply [Max]	Data Rate	Common Mode Transient Immunity (Min) [Min]	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]	Technology	Operating Temperature [Max]	Operating Temperature [Min]	Mounting Type	Supplier Device Package	Package / Case [x]	Package / Case [y]	Package / Case	Package / Case	Rise / Fall Time (Typ) [custom]	Rise / Fall Time (Typ) [custom]
Skyworks Solutions Inc. SI8651BC-AS1R	4.5 ns	Automotive	16-SOIC	0.154 in 3.9 mm	3750 Vrms	1	4	General Purpose	AEC-Q100	Unidirectional	5	13 ns	2.375 V	5.5 V	150 Mbps	35 kV/µs	2.5 ns	2.5 ns	Capacitive Coupling	125 °C	-40 C	Surface Mount	16-SOIC
Skyworks Solutions Inc. SI8651EB-AU	4.5 ns	Automotive	16-SSOP		2500 Vrms	1	4	General Purpose	AEC-Q100	Unidirectional	5	13 ns	2.375 V	5.5 V	150 Mbps	35 kV/µs	2.5 ns	2.5 ns	Capacitive Coupling	125 °C	-40 C	Surface Mount	16-QSOP	0.154 in	3.9 mm
Skyworks Solutions Inc. SI8651ED-B-ISR	4.5 ns		16-SOIC			1	4	General Purpose		Unidirectional	5	13 ns	2.5 V	5.5 V	150 Mbps	35 kV/µs	2.5 ns	2.5 ns	Capacitive Coupling	125 °C	-40 C	Surface Mount	16-SOIC			7.5 mm	0.295 "
Skyworks Solutions Inc. SI8651BB-B-IS1R	4.5 ns		16-SOIC	0.154 in 3.9 mm	2500 Vrms	1	4	General Purpose		Unidirectional	5	13 ns	2.5 V	5.5 V	150 Mbps	35 kV/µs	2.5 ns	2.5 ns	Capacitive Coupling	125 °C	-40 C	Surface Mount	16-SOIC
Skyworks Solutions Inc. SI8651ED-AS	4.5 ns	Automotive	16-SOIC			1	4	General Purpose	AEC-Q100	Unidirectional	5	13 ns	2.375 V	5.5 V	150 Mbps	35 kV/µs	2.5 ns	2.5 ns	Capacitive Coupling	125 °C	-40 C	Surface Mount	16-SOIC			7.5 mm	0.295 "
Skyworks Solutions Inc. SI8651EC-B-IS1R	4.5 ns		16-SOIC	0.154 in 3.9 mm	3750 Vrms	1	4	General Purpose		Unidirectional	5	13 ns	2.5 V	5.5 V	150 Mbps	35 kV/µs	2.5 ns	2.5 ns	Capacitive Coupling	125 °C	-40 C	Surface Mount	16-SOIC
Skyworks Solutions Inc. SI8651EB-B-IUR	4.5 ns		16-SSOP		2500 Vrms	1	4	General Purpose		Unidirectional	5	13 ns	2.5 V	5.5 V	150 Mbps	50 kV/çs			Capacitive Coupling	125 °C	-40 C	Surface Mount	16-QSOP	0.154 in	3.9 mm			4 ns	4 ns
Skyworks Solutions Inc. SI8651ED-B-IS	4.5 ns		16-SOIC			1	4	General Purpose		Unidirectional	5	13 ns	2.5 V	5.5 V	150 Mbps	35 kV/µs	2.5 ns	2.5 ns	Capacitive Coupling	125 °C	-40 C	Surface Mount	16-SOIC			7.5 mm	0.295 "
Skyworks Solutions Inc. SI8651BB-B-IUR	4.5 ns		16-SSOP		2500 Vrms	1	4	General Purpose		Unidirectional	5	13 ns	2.5 V	5.5 V	150 Mbps	50 kV/çs			Capacitive Coupling	125 °C	-40 C	Surface Mount	16-QSOP	0.154 in	3.9 mm			4 ns	4 ns
Skyworks Solutions Inc. SI8651EC-B-IS1	4.5 ns		16-SOIC	0.154 in 3.9 mm	3750 Vrms	1	4	General Purpose		Unidirectional	5	13 ns	2.5 V	5.5 V	150 Mbps	35 kV/µs	2.5 ns	2.5 ns	Capacitive Coupling	125 °C	-40 C	Surface Mount	16-SOIC
