325-050 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 50POS 0.100
| Part | Termination Rows [custom] | Material - Insulation | Mounting Type | Termination | Read Out | Card Thickness | Card Thickness | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Card Type | Number of Positions/Bay/Row | Gender | Number of Rows [custom] | Pitch | Pitch | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Contact Type | Color | Contact Finish | Termination Rows | Number of Rows | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | Solder Eyelet(s) | Dual | 3.18 mm | 0.125 in | Copper Alloy | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 25 | Female | 2 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 50 | Cantilever | Green | Gold | |||||
EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Solder Eyelet(s) | Single | 3.18 mm | 0.125 in | Copper Alloy | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 50 | Female | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 50 | Cantilever | Green | Gold | 1 | 1 | 4-40 Flush Mount Threaded Insert Top Opening | ||||
EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Solder | Single | 3.18 mm | 0.125 in | Copper Alloy | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 50 | Female | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 50 | Cantilever | Green | Gold | 1 | 1 | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Solder Eyelet(s) | Single | 3.18 mm | 0.125 in | Copper Alloy | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 50 | Female | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 50 | Cantilever | Green | Gold | 1 | 1 | |||||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | Solder | Dual | 3.18 mm | 0.125 in | Copper Alloy | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 25 | Female | 2 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 50 | Cantilever | Green | Gold | Flush Mount Top Opening Unthreaded | 0.16 " | 4.06 mm | ||
EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | Wire Wrap | Dual | 3.18 mm | 0.125 in | Copper Alloy | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 25 | Female | 2 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 50 | Cantilever | Green | Gold | |||||
EDAC Inc. | 2 | Diallyl Phthalate (DAP) | Through Hole | Solder | Dual | 3.18 mm | 0.125 in | Copper Alloy | 0.25 Ám | 10 Áin | Non Specified - Dual Edge | 25 | Female | 2 | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 50 | Cantilever | Green | Gold | Flush Mount M3 Threaded Insert Top Opening | ||||
 EDAC Inc. | Diallyl Phthalate (DAP) | Through Hole | Solder Eyelet(s) | Single | 3.18 mm | 0.125 in | Copper Alloy | 0.25 Ám | 10 Áin | Non Specified - Single Edge | 50 | Female | 0.1 " | 2.54 mm | -65 ░C | 125 °C | 50 | Cantilever | Green | Gold | 1 | 1 | Flush Mount M3 Threaded Insert Top Opening |
