T 3477 Series
Manufacturer: Amphenol Tuchel Industrial
Beta
⌘K
CONN RCPT HSNG MALE 7POS PNL MNT
| Part | Mounting Type | Number of Positions | Shell Finish | Contact Size | Fastening Type | Housing Color | Type | Shell Size - Insert | Mounting Feature | Insert Material | Connector Type | Ingress Protection | Material Flammability Rating | Note | Orientation | Shell Material | Shielding | Contact Shape | Operating Temperature [Min] | Operating Temperature [Max] | Contact Type | Termination | Current Rating (Amps) | Voltage Rating | Color | Contact Finish - Mating | Primary Material |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol Tuchel Industrial | Panel Mount | 7 | Nickel | 1.5 mm | Threaded | Silver | For Male Pins | M16-7 | Bulkhead - Rear Side Nut | Thermoplastic | Receptacle Housing | IP40 | UL94 V-0 | Contacts Not Included | Keyed | Die Cast | Shielded | Circular | -40 C | 100 °C | Crimp | ||||||
 Amphenol Tuchel Industrial | Panel Mount Through Hole | 7 | Nickel | Threaded | M16-7 | Receptacle Male Pins | IP40 | Keyed | Die Cast | Shielded | -40 C | 100 °C | Solder | 7 A | 250 V | Silver | Silver | Metal | |||||||||
 Amphenol Tuchel Industrial | Panel Mount | 7 | Nickel | Threaded | M16-7 | Receptacle Male Pins | IP40 | Keyed | Die Cast | Shielded | -40 C | 100 °C | 7 A | 250 V | Silver | Gold | Metal | ||||||||||
 Amphenol Tuchel Industrial | Panel Mount | 7 | Nickel | Threaded | M16-7 | Receptacle Male Pins | IP40 | Keyed | Die Cast | Shielded | -40 C | 100 °C | 7 A | 250 V | Silver | Silver | Metal | ||||||||||
 Amphenol Tuchel Industrial | Panel Mount | 7 | Nickel | Threaded | M16-7 | Bulkhead - Rear Side Nut | Receptacle Male Pins | IP40 | Keyed | Die Cast | Shielded | -40 C | 100 °C | 7 A | 250 V | Silver | Silver | Metal |
