CP2816 Series
Manufacturer: KYOCERA AVX
Beta
⌘K
CP2816 SERIES, 20W THIN FILM COU
| Part | Package / Case | Supplier Device Package | Frequency [Max] | Frequency [Min] | Coupler Type | Applications | Insertion Loss | Coupling Factor | Power - Max [Max] |
|---|---|---|---|---|---|---|---|---|---|
 KYOCERA AVX | 4-SMD No Lead | 4-SMD | 512 MHz | 225 MHz | Standard | General Purpose | -1.7 dB | -15 dB | 20 W |
KYOCERA AVX | 4-SMD No Lead | 4-SMD | 337 MHz | 225 MHz | Standard | General Purpose | -1 dB | -10 dB | 20 W |
KYOCERA AVX | 4-SMD No Lead | 4-SMD | 750 MHz | 600 MHz | Standard | General Purpose | -1 dB | -10 dB | 20 W |
KYOCERA AVX | 4-SMD No Lead | 4-SMD | 750 MHz | 480 MHz | Standard | General Purpose | -1 dB | -15.2 dB | 20 W |
KYOCERA AVX | 4-SMD No Lead | 4-SMD | 512 MHz | 337 MHz | Standard | General Purpose | -1 dB | -10 dB | 20 W |
