D09S33 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN D-SUB RCPT 9POS R/A SOLDER
| Part | Contact Material | Backset Spacing | Backset Spacing | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Color | Connector Style | Material Flammability Rating | Features | Flange Feature | Connector Type | Contact Finish Thickness | Contact Finish Thickness | Number of Positions | Number of Rows | Contact Finish | Voltage Rating | Mounting Type | Current Rating (Amps) | Contact Type | Termination | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Contact Finish Thickness | Shell Material, Finish | Operating Temperature |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Amphenol ICC (FCI) | Phosphor Bronze | 8.08 mm | 0.318 " | Polybutylene Terephthalate (PBT) | -55 °C | 125 °C | Black | D-Sub | UL94 V-0 | Board Lock Mounting Brackets | Female Screwlock (4-40) Mating Side | Receptacle Female Sockets | 0.76 Ám | 30 Áin | 9 | 2 | Gold | 300 VDC | Through Hole Right Angle | 5 A | Signal | Solder | DE E | 1 | |||
Amphenol ICC (FCI) | Phosphor Bronze | 8.08 mm | 0.318 " | Polybutylene Terephthalate (PBT) | -55 °C | 125 °C | Black | D-Sub | UL94 V-0 | Board Lock Mounting Brackets | Housing/Shell (4-40) | Receptacle Female Sockets | 0.76 Ám | 30 Áin | 9 | 2 | Gold | 300 VDC | Through Hole Right Angle | 5 A | Signal | Solder | DE E | 1 | |||
 Amphenol ICC (FCI) | Phosphor Bronze | 8.08 mm | 0.318 " | Polybutylene Terephthalate (PBT) | -55 °C | 125 °C | Black | D-Sub | UL94 V-0 | Board Lock Mounting Brackets | Female Screwlock (4-40) Mating Side | Receptacle Female Sockets | 9 | 2 | Gold | 300 VDC | Through Hole Right Angle | 5 A | Signal | Solder | DE E | 1 | Flash | ||||
 Amphenol ICC (FCI) | Phosphor Bronze | 8.08 mm | 0.318 " | Polybutylene Terephthalate (PBT) | -55 °C | 125 °C | Black | D-Sub | UL94 V-0 | Board Lock Mounting Brackets | Housing/Shell (4-40) | Receptacle Female Sockets | 9 | 2 | Gold | 300 VDC | Through Hole Right Angle | 5 A | Signal | Solder | DE E | 1 | Flash | ||||
Amphenol ICC (FCI) | Phosphor Bronze | 8.08 mm | 0.318 " | Polyester | -55 °C | 125 °C | Black | D-Sub | UL94 V-0 | Mounting Brackets | Female Screwlock (4-40) Mating Side | Receptacle Female Sockets | 9 | 2 | Gold | 300 VDC | Through Hole Right Angle | 5 A | Signal | Solder | DE E | 1 | Flash | Steel Tin-Nickel Plated | |||
 Amphenol ICC (FCI) | Phosphor Bronze | 8.08 mm | 0.318 " | Glass Filled Nylon Polyamide (PA) | Black | D-Sub | UL94 V-0 | Board Guide Mounting Brackets | Female Screwlock (4-40) Mating Side | Receptacle Female Sockets | 0.76 Ám | 30 Áin | 9 | 2 | Gold or Gold GXT™ | 300 VDC | Through Hole Right Angle | 5 A | Signal | Solder Paste | DE E | 1 | Nickel Plated Steel | -55 °C | |||
 Amphenol ICC (FCI) | Phosphor Bronze | 8.08 mm | 0.318 " | Glass Filled Nylon Polyamide (PA) | Black | D-Sub | UL94 V-0 | Board Guide Mounting Brackets | Housing/Shell (4-40) | Receptacle Female Sockets | 0.76 Ám | 30 Áin | 9 | 2 | Gold | 300 VDC | Through Hole Right Angle | 5 A | Signal | Solder Paste | DE E | 1 | Nickel Plated Steel | -55 °C | |||
Amphenol ICC (FCI) | Phosphor Bronze | 8.08 mm | 0.318 " | Thermoplastic | -55 °C | 125 °C | Black | D-Sub | UL94 V-0 | Mounting Brackets | Female Screwlock (4-40) Mating Side | Receptacle Female Sockets | 0.76 Ám | 30 Áin | 9 | 2 | Gold | 300 VDC | Through Hole Right Angle | 5 A | Signal | Solder | DE E | 1 | Steel Tin-Nickel Plated | ||
Amphenol ICC (FCI) | Phosphor Bronze | 8.08 mm | 0.318 " | Glass Filled Nylon Polyamide (PA) | Black | D-Sub | UL94 V-0 | Board Guide Mounting Brackets | Housing/Shell (4-40) | Receptacle Female Sockets | 9 | 2 | Gold | 300 VDC | Through Hole Right Angle | 5 A | Signal | Solder Paste | DE E | 1 | Flash | Nickel Plated Steel | -55 °C | ||||
Amphenol ICC (FCI) | Phosphor Bronze | 8.08 mm | 0.318 " | Thermoplastic | -55 °C | 125 °C | Black | D-Sub | UL94 V-0 | Housing/Shell (Unthreaded) | Receptacle Female Sockets | 0.76 Ám | 30 Áin | 9 | 2 | Gold | 300 VDC | Through Hole Right Angle | 5 A | Signal | Solder | DE E | 1 |
