1744357 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN HEADER VERT 3POS 3.96MM
| Part | Applications | Pitch - Mating | Pitch - Mating | Number of Positions Loaded | Contact Type | Insulation Material | Number of Rows | Material Flammability Rating | Contact Shape | Style | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Contact Material | Features | Contact Finish - Post | Voltage Rating | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Insulation Color | Connector Type | Insulation Height | Insulation Height | Shrouding | Mounting Type | Fastening Type | Contact Length - Mating | Contact Length - Mating | Number of Positions Loaded | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | General Purpose Industrial Lighting | 0.156 in | 3.96 mm | All | Male Pin | Polybutylene Terephthalate (PBT) Glass Filled | 1 | UL94 V-0 | Square | Board to Cable/Wire | -25 °C | 105 ░C | Solder | Brass | Board Guide | Tin | 250 VAC | 1 çm | 39.4 çin | 1 µm | 39.4 µin | Natural | Header | 0.472 in | 12 mm | Shrouded - 2 Wall | Through Hole | Locking Ramp | 0.306 in | 7.77 mm | ||
TE Connectivity Raychem Cable Protection | General Purpose Industrial Lighting | 0.156 in | 3.96 mm | Male Pin | Polybutylene Terephthalate (PBT) Glass Filled | 1 | UL94 V-0 | Square | Board to Cable/Wire | -25 °C | 105 ░C | Solder | Brass | Board Guide | Tin | 250 VAC | 1 çm | 39.4 çin | 1 µm | 39.4 µin | Natural | Header | 0.472 in | 12 mm | Shrouded - 2 Wall | Through Hole | Locking Ramp | 0.306 in | 7.77 mm | 4 | ||
 TE Connectivity Raychem Cable Protection | General Purpose Industrial Lighting | 0.156 in | 3.96 mm | All | Male Pin | Polybutylene Terephthalate (PBT) Glass Filled | 1 | UL94 V-0 | Square | Board to Cable/Wire | -25 °C | 105 ░C | Solder | Brass | Board Guide | Tin | 250 VAC | 1 çm | 39.4 çin | 1 µm | 39.4 µin | Natural | Header | 0.472 in | 12 mm | Shrouded - 2 Wall | Through Hole | Locking Ramp | 0.306 in | 7.77 mm | 7 |
