837-008 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 8POS 0.156
| Part | Termination Rows | Material - Insulation | Number of Positions/Bay/Row | Number of Positions | Number of Rows | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Operating Temperature [Max] | Operating Temperature [Min] | Card Type | Gender | Read Out | Mounting Type | Pitch | Pitch | Termination | Contact Type | Contact Finish Thickness | Contact Finish Thickness | Contact Material | Color | Card Thickness [Max] | Card Thickness [Min] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 8 | 8 | 1 | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Single | Through Hole | 3.96 mm | 0.156 in | Wire Wrap | Cantilever | 0.25 Ám | 10 Áin | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 8 | 8 | 1 | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Single | Through Hole | 3.96 mm | 0.156 in | Solder | Cantilever | 0.25 Ám | 10 Áin | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 8 | 8 | 1 | M3 Threaded Insert Top Mount Opening | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Single | Through Hole | 3.96 mm | 0.156 in | Solder | Cantilever | 0.25 Ám | 10 Áin | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 8 | 8 | 1 | 0.156 " | 3.96 mm | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Single | Through Hole | 3.96 mm | 0.156 in | Solder | Cantilever | 0.25 Ám | 10 Áin | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 8 | 8 | 1 | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Single | Right Angle Through Hole | 3.96 mm | 0.156 in | Solder | Cantilever | 0.25 Ám | 10 Áin | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 8 | 8 | 1 | 4-40 Flush Mount Threaded Insert Top Opening | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Single | Through Hole | 3.96 mm | 0.156 in | Wire Wrap | Cantilever | 0.25 Ám | 10 Áin | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm | ||
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 8 | 8 | 1 | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Single | Right Angle Through Hole | 3.96 mm | 0.156 in | Solder | Cantilever | 0.25 Ám | 10 Áin | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 8 | 8 | 1 | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Single | Right Angle Through Hole | 3.96 mm | 0.156 in | Solder | Cantilever | 0.25 Ám | 10 Áin | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 8 | 8 | 1 | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Single | Through Hole | 3.96 mm | 0.156 in | Wire Wrap | Cantilever | 0.25 Ám | 10 Áin | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
 EDAC Inc. | 1 | Diallyl Phthalate (DAP) | 8 | 8 | 1 | Flush Mount Top Opening Unthreaded | 0.128 " | 3.25 mm | Gold | 125 °C | -40 C | Non Specified - Single Edge | Female | Single | Through Hole | 3.96 mm | 0.156 in | Wire Wrap | Cantilever | 0.25 Ám | 10 Áin | Copper Alloy | Green | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
