T9GV2 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RELAY GEN PURPOSE SPST 20A 12V
| Part | Coil Resistance | Contact Form | Operating Temperature [Min] | Operating Temperature [Max] | Mounting Type | Switching Voltage [Max] | Coil Type | Relay Type | Coil Insulation | Termination Style | Load - Max Switching [Max] | Contact Rating (Current) | Operate Time | Coil Current | Must Operate Voltage | Approval Agency | Contact Material | Seal Rating | Coil Voltage | Must Release Voltage | Release Time |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 160 Ohms | SPST-NC (1 Form B) | -40 C | 105 ░C | Through Hole | 480 VAC | Non Latching | General Purpose | Class B | PC Pin Quick Connect - 0.250" (6.3mm) | 9600 VA | 20 A | 15 ms | 0.075 A | 9 VDC | CQC cURus VDE | Silver Tin Oxide (AgSnO) | Sealed - Flux Protection | 12 VDC | 1.2 VDC | 22 ms |
 TE Connectivity AMP Connectors | 2500 Ohms | SPST-NC (1 Form B) | -40 C | 105 ░C | Through Hole | 480 VAC | Non Latching | General Purpose | Class B | PC Pin | 9600 VA | 20 A | 15 ms | 18.8 mA | 36 VDC | CQC cURus VDE | Silver Tin Oxide (AgSnO) | Sealed - Flux Protection | 48 VDC | 4.8 VDC | 22 ms |
 TE Connectivity AMP Connectors | 360 Ohms | SPST-NC (1 Form B) | -40 C | 105 ░C | Through Hole | 480 VAC | Non Latching | General Purpose | Class B | PC Pin Quick Connect - 0.250" (6.3mm) | 9600 VA | 20 A | 15 ms | 50 mA | 13.5 VDC | CQC cURus VDE | Silver Tin Oxide (AgSnO) | Sealed - Flux Protection | 18 VDC | 1.8 VDC | 22 ms |
 TE Connectivity AMP Connectors | 360 Ohms | SPST-NC (1 Form B) | -40 C | 105 ░C | Through Hole | 480 VAC | Non Latching | General Purpose | Class B | PC Pin | 9600 VA | 20 A | 15 ms | 50 mA | 13.5 VDC | CQC cURus VDE | Silver Tin Oxide (AgSnO) | Sealed - Flux Protection | 18 VDC | 1.8 VDC | 22 ms |
 TE Connectivity AMP Connectors | 13.4 kOhms | SPST-NC (1 Form B) | -40 C | 105 ░C | Through Hole | 480 VAC | Non Latching | General Purpose | Class B | PC Pin | 9600 VA | 20 A | 15 ms | 8.2 mA | 82.5 VDC | CQC cURus VDE | Silver Tin Oxide (AgSnO) | Sealed - Flux Protection | 110 VDC | 11 VDC | 22 ms |
 TE Connectivity AMP Connectors | 538 Ohms | SPST-NC (1 Form B) | -40 C | 105 ░C | Through Hole | 480 VAC | Non Latching | General Purpose | Class B | PC Pin Quick Connect - 0.250" (6.3mm) | 9600 VA | 20 A | 15 ms | 41 mA | 16.5 VDC | CQC cURus VDE | Silver Tin Oxide (AgSnO) | Sealed - Flux Protection | 22 VDC | 2.2 VDC | 22 ms |
TE Connectivity AMP Connectors | 249 Ohms | SPST-NC (1 Form B) | -40 C | 105 ░C | Through Hole | 480 VAC | Non Latching | General Purpose | Class B | PC Pin Quick Connect - 0.250" (6.3mm) | 9600 VA | 20 A | 15 ms | 0.06 A | 11.25 VDC | CQC cURus VDE | Silver Tin Oxide (AgSnO) | Sealed - Flux Protection | 15 VDC | 1.5 VDC | 22 ms |
 TE Connectivity AMP Connectors | 90 Ohms | SPST-NC (1 Form B) | -40 C | 105 ░C | Through Hole | 480 VAC | Non Latching | General Purpose | Class B | PC Pin | 9600 VA | 20 A | 15 ms | 0.1 A | 6.75 VDC | CQC cURus VDE | Silver Tin Oxide (AgSnO) | Sealed - Flux Protection | 9 VDC | 0.9 VDC | 22 ms |
