PB01D Series
Manufacturer: Delta Electronics
Beta
⌘K
DC DC CONVERTER +/-15V 1W
| Part | Number of Outputs | Type | Voltage - Input (Min) [Min] | Operating Temperature [Max] | Operating Temperature [Min] | Applications | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Package / Case | Voltage - Output 2 | Current - Output (Max) [Max] | Current - Output (Max) [Max] | Voltage - Input (Max) [Max] | Voltage - Output 1 | Mounting Type | Features | Voltage - Isolation | Efficiency |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Delta Electronics | 2 | Isolated Module | 21.6 V | 85 °C | -40 C | Medical | 0.4 " | 0.24 " | 0.77 in | 6 mm | 10.2 mm | 19.6 mm | 5-SIP Module | -15 V | 34 mA | 34 mA | 26.4 V | 15 V | Through Hole | SCP | 1000 V | 80 % |
