STR-X6769 Series

Catalog

IC OFFLINE SW FLYBACK TO3PF-7

Part	Fault Protection	Voltage - Supply (Vcc/Vdd) [Max]	Voltage - Supply (Vcc/Vdd) [Min]	Package / Case	Supplier Device Package	Frequency - Switching [Min]	Frequency - Switching [Max]	Mounting Type	Voltage - Start Up	Output Isolation	Control Features	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Breakdown	Power (Watts)	Topology	Internal Switch(s)
Sanken Electric USA Inc. STR-X6769	Current Limiting Over Load Over Voltage	35 V	9.7 V	TO-3P-7 Full Pack Formed Leads	TO-3P	19 kHz	25 kHz	Through Hole	18.2 V	Isolated	Soft Start	125 °C	-20 °C	800 V	310 W	Flyback
Sanken Electric USA Inc. STR-X6769B	Current Limiting Over Load Over Voltage	35 V	9.7 V	TO-3P-7 Full Pack Formed Leads	TO-3P	19 kHz	25 kHz	Through Hole	18.2 V	Isolated	Soft Start	125 °C	-20 °C	800 V		Flyback
