846-052 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 52POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Gender | Number of Positions/Bay/Row | Pitch | Pitch | Color | Card Type | Number of Positions | Card Thickness [Max] | Card Thickness [Min] | Termination | Contact Type | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Read Out | Number of Rows [custom] | Contact Finish | Mounting Type | Contact Finish Thickness | Contact Finish Thickness | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Female | 26 | 3.18 mm | 0.125 in | Green | Non Specified - Dual Edge | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Cantilever | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Dual | 2 | Gold | Right Angle Through Hole | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Female | 26 | 3.18 mm | 0.125 in | Green | Non Specified - Dual Edge | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Cantilever | 0.156 " | 3.96 mm | Dual | 2 | Gold | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Card Extender | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Female | 26 | 3.18 mm | 0.125 in | Green | Non Specified - Dual Edge | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Dual | 2 | Gold | Right Angle Through Hole | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Female | 26 | 3.18 mm | 0.125 in | Green | Non Specified - Dual Edge | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Cantilever | M3 Threaded Insert Top Mount Opening | Dual | 2 | Gold | Board Edge Straddle Mount | 0.25 Ám | 10 Áin | Card Extender | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Female | 26 | 3.18 mm | 0.125 in | Green | Non Specified - Dual Edge | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Cantilever | 0.128 " | 3.25 mm | Dual | 2 | Gold | Through Hole | 0.25 Ám | 10 Áin | ||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Female | 26 | 3.18 mm | 0.125 in | Green | Non Specified - Dual Edge | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Dual | 2 | Gold | Through Hole | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Female | 26 | 3.18 mm | 0.125 in | Green | Non Specified - Dual Edge | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Cantilever | 4-40 Flush Mount Threaded Insert Top Opening | Dual | 2 | Gold | Through Hole | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Female | 26 | 3.18 mm | 0.125 in | Green | Non Specified - Dual Edge | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Cantilever | Flush Mount M3 Threaded Insert Top Opening | Dual | 2 | Gold | Through Hole | 0.25 Ám | 10 Áin | |||
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Female | 26 | 3.18 mm | 0.125 in | Green | Non Specified - Dual Edge | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Cantilever | Flush Mount Side Opening Unthreaded | 0.128 " | 3.25 mm | Dual | 2 | Gold | Through Hole | 0.25 Ám | 10 Áin | |
 EDAC Inc. | 2 | Diallyl Phthalate (DAP) | 125 °C | -40 C | Copper Alloy | Female | 26 | 3.18 mm | 0.125 in | Green | Non Specified - Dual Edge | 52 | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Cantilever | Dual | 2 | Gold | Through Hole | 0.25 Ám | 10 Áin |
