RTQ020 Series

Catalog

NCH 45V 2A SMALL SIGNAL MOSFET

Part	Vgs(th) (Max) @ Id	Package / Case	Drive Voltage (Max Rds On, Min Rds On) [Max]	Drive Voltage (Max Rds On, Min Rds On) [Min]	Technology	Input Capacitance (Ciss) (Max) @ Vds	Gate Charge (Qg) (Max) @ Vgs	Current - Continuous Drain (Id) @ 25°C	Power Dissipation (Max) [Max]	Vgs (Max)	FET Type	Drain to Source Voltage (Vdss)	Supplier Device Package	Mounting Type	Operating Temperature	Rds On (Max) @ Id, Vgs	Input Capacitance (Ciss) (Max) @ Vds [Max]
Rohm Semiconductor RTQ020N05TR	1.5 V	SOT-23-6 Thin TSOT-23-6	2.5 V	4.5 V	MOSFET (Metal Oxide)	150 pF	2.3 nC	2 A	600 mW	12 V	N-Channel	45 V	TSMT6 (SC-95)	Surface Mount	150 °C	190 mOhm
Rohm Semiconductor RTQ020N03TR	1.5 V	SOT-23-6 Thin TSOT-23-6	2.5 V	4.5 V	MOSFET (Metal Oxide)		3.3 nC	2 A	1.25 W	12 V	N-Channel	30 V	TSMT6 (SC-95)	Surface Mount	150 °C	125 mOhm	135 pF
