629W9W Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN D-SUB PLUG 9POS R/A SLDR
| Part | Color | Voltage Rating | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Contact Material | Features | Connector Style | Contact Type | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [x] | Termination | Contact Finish | Material Flammability Rating | Number of Rows [custom] | Shell Material, Finish | Current Rating (Amps) | Flange Feature | Flange Feature | Mounting Type | Connector Type | Number of Positions [custom] | Number of Positions [custom] | Contact Finish Thickness | Ingress Protection | Contact Finish Thickness | Contact Finish Thickness | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Black | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | Copper Alloy | Board Lock Grounding Indents Mounting Brackets Shielded | Combo D-Sub | Signal and Power | DB B - 9W4 | 3 | Solder | Gold | UL94 V-0 | 2 | Nickel Plated Steel | 20A 5A | Housing/Shell | 4-40 | Panel Mount Right Angle Through Hole | Plug Male Pins | 4 | 5 | Flash | IP67 - Dust Tight Waterproof | |||
 EDAC Inc. | Black | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | Copper Alloy | Board Lock Grounding Indents Mounting Brackets Shielded | Combo D-Sub | Signal and Power | DB B - 9W4 | 3 | Solder | Gold | UL94 V-0 | 2 | Nickel Plated Steel | Housing/Shell | 4-40 | Panel Mount Right Angle Through Hole | Plug Male Pins | 4 | 5 | IP67 - Dust Tight Waterproof | 30 Áin | 0.76 Ám | 5 A 40 A | ||
 EDAC Inc. | Black | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | Copper Alloy | Grounding Indents Mounting Brackets Shielded | Combo D-Sub | Signal and Power | DB B - 9W4 | 3 | Solder | Gold | UL94 V-0 | 2 | Nickel Plated Steel | Housing/Shell (M3) | Right Angle Through Hole | Plug Male Pins | 4 | 5 | Flash | IP67 - Dust Tight Waterproof | 5 A 40 A | ||||
 EDAC Inc. | Black | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | Copper Alloy | Board Lock Filter Grounding Indents Mounting Brackets Shielded | Combo D-Sub | Signal and Power | DB B - 9W4 | 3 | Solder | Gold | UL94 V-0 | 2 | Nickel Plated Steel | 20A 5A | Housing/Shell (M3) | Panel Mount Right Angle Through Hole | Plug Male Pins | 4 | 5 | IP67 - Dust Tight Waterproof | 5 µin | 0.127 µm | |||
 EDAC Inc. | Black | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | Copper Alloy | Grounding Indents Shielded | Combo D-Sub | Signal and Power | DB B - 9W4 | 3 | Solder | Gold | UL94 V-0 | 2 | Nickel Plated Steel | Housing/Shell | 4-40 | Panel Mount Right Angle Through Hole | Plug Male Pins | 4 | 5 | IP67 - Dust Tight Waterproof | 5 µin | 0.127 µm | 5 A 40 A | ||
 EDAC Inc. | Black | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | Copper Alloy | Grounding Indents Shielded | Combo D-Sub | Signal and Power | DB B - 9W4 | 3 | Solder | Gold | UL94 V-0 | 2 | Nickel Plated Steel | 20A 5A | Housing/Shell (M3) | Panel Mount Right Angle Through Hole | Plug Male Pins | 4 | 5 | IP67 - Dust Tight Waterproof | 5 µin | 0.127 µm | |||
 EDAC Inc. | Black | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | Copper Alloy | Board Lock Grounding Indents Mounting Brackets Shielded | Combo D-Sub | Signal and Power | DB B - 9W4 | 3 | Solder | Gold | UL94 V-0 | 2 | Nickel Plated Steel | Housing/Shell | 4-40 | Panel Mount Right Angle Through Hole | Plug Male Pins | 4 | 5 | IP67 - Dust Tight Waterproof | 15 µin | 0.38 µm | 5 A 30 A | ||
 EDAC Inc. | Black | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | Copper Alloy | Grounding Indents Shielded | Combo D-Sub | Signal and Power | DB B - 9W4 | 3 | Solder | Gold | UL94 V-0 | 2 | Nickel Plated Steel | Housing/Shell | 4-40 | Panel Mount Right Angle Through Hole | Plug Male Pins | 4 | 5 | Flash | IP67 - Dust Tight Waterproof | 5 A 30 A | |||
 EDAC Inc. | Black | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | Copper Alloy | Grounding Indents Mounting Brackets Shielded | Combo D-Sub | Signal and Power | DB B - 9W4 | 3 | Solder | Gold | UL94 V-0 | 2 | Nickel Plated Steel | 10A 5A | Housing/Shell | 4-40 | Panel Mount Right Angle Through Hole | Plug Male Pins | 4 | 5 | IP67 - Dust Tight Waterproof | 30 Áin | 0.76 Ám | ||
 EDAC Inc. | Black | 125 VDC | Polybutylene Terephthalate (PBT) Glass Filled | -55 C | 125 °C | Copper Alloy | Grounding Indents Shielded | Combo D-Sub | Signal and Power | DB B - 9W4 | 3 | Solder | Gold | UL94 V-0 | 2 | Nickel Plated Steel | Housing/Shell | 4-40 | Panel Mount Right Angle Through Hole | Plug Male Pins | 4 | 5 | Flash | IP67 - Dust Tight Waterproof | 5 A 40 A |
