H2UN3 Series

Catalog

UNICTRON CX40D9 - 5G FR1 CHIP AN

Part	Mounting Type	Termination	Frequency (Center/Band)	RF Family/Standard	Number of Bands	Height (Max) [z]	Height (Max) [z]	Frequency Range [Max]	Frequency Range [Min]	Frequency Group	Antenna Type	Power - Max [Max]	Gain	Applications
Unictron Technologies Corporation H2UN3P1D2V0100	Surface Mount	Solder	1.94 GHz 2.495 GHz 3.75 GHz 4.7 GHz 5.5375 GHz 788.5 MHz	Cellular	6	6 mm	0.236 in	2.17 GHz 2.69 GHz 4.2 GHz 5 GHz 5.925 GHz 960 MHz	1.71 GHz 2.3 GHz 3.3 GHz 4.4 GHz 5.15 GHz 617 MHz	Wide Band	Chip	2 W	1.5 dBi 2.5 dBi 2.6 dBi 2.7 dBi 3 dBi 3.5 dBi	4G 5G
