M20-999 Series

Catalog

BOARD-TO-BOARD CONNECTOR, M20 SERIES, THROUGH HOLE, HEADER, 8, 2.54 MM, TIN PLATED CONTACTS ROHS COMPLIANT: YES

Part	Mated Stacking Heights	Contact Finish - Post	Material Flammability Rating	Connector Type	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Number of Rows	Insulation Material	Number of Positions Loaded	Insulation Height	Insulation Height	Overall Contact Length [x]	Overall Contact Length [x]	Shrouding	Style	Contact Shape	Contact Length - Mating [x]	Contact Length - Mating [x]	Current Rating (Amps)	Contact Type	Insulation Color	Contact Material	Contact Length - Post	Contact Length - Post	Termination	Fastening Type	Pitch - Mating	Pitch - Mating	Number of Positions	Contact Finish - Mating
Harwin Inc. M20-9990846	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Tin	UL94 V-0	Header Cuttable	Through Hole	-40 C	105 ░C	1	Nylon 6T Polyamide (PA6T)	All	0.1 in	2.54 mm	0.46 in	11.68 mm	Unshrouded	Board to Board Cable	Square	0.24 in	6.1 mm	3 A	Male Pin	Black	Brass	0.118 in	3 mm	Solder	Push-Pull	0.1 "	2.54 mm	8
Harwin Inc. M20-9991646	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Tin	UL94 V-0	Header Cuttable	Through Hole	-40 C	105 ░C	1	Nylon 6T Polyamide (PA6T)	All	0.1 in	2.54 mm	0.46 in	11.68 mm	Unshrouded	Board to Board Cable	Square	0.24 in	6.1 mm	3 A	Male Pin	Black	Brass	0.118 in	3 mm	Solder	Push-Pull	0.1 "	2.54 mm	16
Harwin Inc. M20-9990645	10.04 mm 10.64 mm 11.04 mm 16.54 mm		UL94 V-0	Header Cuttable	Through Hole	-40 C	105 ░C	1	Nylon 6T Polyamide (PA6T)	All	0.1 in	2.54 mm	0.46 in	11.68 mm	Unshrouded	Board to Board Cable	Square	0.24 in	6.1 mm	3 A	Male Pin	Black	Brass	0.118 in	3 mm	Solder	Push-Pull	0.1 "	2.54 mm	6	Gold
Harwin Inc. M20-9990745	10.04 mm 10.64 mm 11.04 mm 16.54 mm		UL94 V-0	Header Cuttable	Through Hole	-40 C	105 ░C	1	Nylon 6T Polyamide (PA6T)	All	0.1 in	2.54 mm	0.46 in	11.68 mm	Unshrouded	Board to Board Cable	Square	0.24 in	6.1 mm	3 A	Male Pin	Black	Brass	0.118 in	3 mm	Solder	Push-Pull	0.1 "	2.54 mm	7	Gold
Harwin Inc. M20-9990446	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Tin	UL94 V-0	Header Cuttable	Through Hole	-40 C	105 ░C	1	Nylon 6T Polyamide (PA6T)	All	0.1 in	2.54 mm	0.46 in	11.68 mm	Unshrouded	Board to Board Cable	Square	0.24 in	6.1 mm	3 A	Male Pin	Black	Brass	0.118 in	3 mm	Solder	Push-Pull	0.1 "	2.54 mm	4
Harwin Inc. M20-9991546	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Tin	UL94 V-0	Header Cuttable	Through Hole	-40 C	105 ░C	1	Nylon 6T Polyamide (PA6T)	All	0.1 in	2.54 mm	0.46 in	11.68 mm	Unshrouded	Board to Board Cable	Square	0.24 in	6.1 mm	3 A	Male Pin	Black	Brass	0.118 in	3 mm	Solder	Push-Pull	0.1 "	2.54 mm	15
Harwin Inc. M20-9990545	10.04 mm 10.64 mm 11.04 mm 16.54 mm		UL94 V-0	Header Cuttable	Through Hole	-40 C	105 ░C	1	Nylon 6T Polyamide (PA6T)	All	0.1 in	2.54 mm	0.46 in	11.68 mm	Unshrouded	Board to Board Cable	Square	0.24 in	6.1 mm	3 A	Male Pin	Black	Brass	0.118 in	3 mm	Solder	Push-Pull	0.1 "	2.54 mm	5	Gold
Harwin Inc. M20-9990946	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Tin	UL94 V-0	Header Cuttable	Through Hole	-40 C	105 ░C	1	Nylon 6T Polyamide (PA6T)	All	0.1 in	2.54 mm	0.46 in	11.68 mm	Unshrouded	Board to Board Cable	Square	0.24 in	6.1 mm	3 A	Male Pin	Black	Brass	0.118 in	3 mm	Solder	Push-Pull	0.1 "	2.54 mm	9
Harwin Inc. M20-9992046	10.04 mm 10.64 mm 11.04 mm 16.54 mm	Tin	UL94 V-0	Header Cuttable	Through Hole	-40 C	105 ░C	1	Nylon 6T Polyamide (PA6T)	All	0.1 in	2.54 mm	0.46 in	11.68 mm	Unshrouded	Board to Board Cable	Square	0.24 in	6.1 mm	3 A	Male Pin	Black	Brass	0.118 in	3 mm	Solder	Push-Pull	0.1 "	2.54 mm	20
Harwin Inc. M20-9991645	10.04 mm 10.64 mm 11.04 mm 16.54 mm		UL94 V-0	Header Cuttable	Through Hole	-40 C	105 ░C	1	Nylon 6T Polyamide (PA6T)	All	0.1 in	2.54 mm	0.46 in	11.68 mm	Unshrouded	Board to Board Cable	Square	0.24 in	6.1 mm	3 A	Male Pin	Black	Brass	0.118 in	3 mm	Solder	Push-Pull	0.1 "	2.54 mm	16	Gold
