314-87 Series
Manufacturer: Preci-Dip
Beta
⌘K
CONN SOCKET 5POS 0.1 GOLD SMD
| Part | Contact Shape | Insulation Material | Contact Material | Contact Type | Contact Finish - Mating | Insulation Height | Insulation Height | Current Rating (Amps) | Pitch - Mating | Pitch - Mating | Termination | Material Flammability Rating | Insulation Color | Number of Positions Loaded | Operating Temperature [Min] | Operating Temperature [Max] | Connector Type | Fastening Type | Contact Finish - Post | Contact Finish Thickness - Mating | Mounting Type | Number of Positions | Number of Rows |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Female Socket | Gold | 0.165 in | 4.2 mm | 3 A | 0.1 " | 2.54 mm | Solder | UL94 V-0 | Black | All | -55 C | 125 °C | Socket | Push-Pull | Tin | Flash | Surface Mount | 5 | 1 |
 Preci-Dip | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Female Socket | Gold | 0.165 in | 4.2 mm | 3 A | 0.1 " | 2.54 mm | Solder | UL94 V-0 | Black | All | -55 C | 125 °C | Socket | Push-Pull | Tin | Flash | Surface Mount | 1 | |
Preci-Dip | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Female Socket | Gold | 0.165 in | 4.2 mm | 3 A | 0.1 " | 2.54 mm | Solder | UL94 V-0 | Black | All | -55 C | 125 °C | Socket | Push-Pull | Tin | Flash | Surface Mount | 8 | 1 |
Preci-Dip | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Female Socket | Gold | 0.165 in | 4.2 mm | 3 A | 0.1 " | 2.54 mm | Solder | UL94 V-0 | Black | All | -55 C | 125 °C | Socket | Push-Pull | Tin | Flash | Surface Mount | 9 | 1 |
Preci-Dip | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Female Socket | Gold | 0.165 in | 4.2 mm | 3 A | 0.1 " | 2.54 mm | Solder | UL94 V-0 | Black | All | -55 C | 125 °C | Socket | Push-Pull | Tin | Flash | Surface Mount | 7 | 1 |
Preci-Dip | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Female Socket | Gold | 0.165 in | 4.2 mm | 3 A | 0.1 " | 2.54 mm | Solder | UL94 V-0 | Black | All | -55 C | 125 °C | Socket | Push-Pull | Tin | Flash | Surface Mount | 6 | 1 |
 Preci-Dip | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Female Socket | Gold | 0.165 in | 4.2 mm | 3 A | 0.1 " | 2.54 mm | Solder | UL94 V-0 | Black | All | -55 C | 125 °C | Socket | Push-Pull | Tin | Flash | Surface Mount | 4 | 1 |
Preci-Dip | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Female Socket | Gold | 0.165 in | 4.2 mm | 3 A | 0.1 " | 2.54 mm | Solder | UL94 V-0 | Black | All | -55 C | 125 °C | Socket | Push-Pull | Tin | Flash | Surface Mount | 1 | |
Preci-Dip | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Female Socket | Gold | 0.165 in | 4.2 mm | 3 A | 0.1 " | 2.54 mm | Solder | UL94 V-0 | Black | All | -55 C | 125 °C | Socket | Push-Pull | Tin | Flash | Surface Mount | 6 | 1 |
Preci-Dip | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Beryllium Copper | Female Socket | Gold | 0.165 in | 4.2 mm | 3 A | 0.1 " | 2.54 mm | Solder | UL94 V-0 | Black | All | -55 C | 125 °C | Socket | Push-Pull | Tin | Flash | Surface Mount | 4 | 1 |
