71AD30 Series
Manufacturer: Grayhill Inc.
Beta
⌘K
SWITCH ROTARY 2-4POS 250MA 115V
| Part | Current Rating (Amps) | Contact Timing | Actuator Type | Number of Decks | Depth Behind Panel | Angle of Throw | Termination Style | Mounting Type | Number of Positions [Min] | Number of Positions [Max] | Circuit per Deck | Number of Poles per Deck | Actuator Length [x] | Contact Material | Voltage Rating - DC | Index Stops | Voltage Rating - AC | Depth Behind Panel [z] | Number of Decks [custom] | Depth Behind Panel [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Grayhill Inc. | 250 mA | Non-Shorting (BBM) | Flatted (3.17mm Dia) | 2 | 24.87 mm | 30 ° | Solder Lug | Panel Mount | 2 | 4 | 3P4T | 3 | 9.53 mm | Silver Alloy | 30 V | Adjustable | 115 V | |||
Grayhill Inc. | 250 mA | Shorting (MBB) | Flatted (3.17mm Dia) | 2 | 24.87 mm | 30 ° | Solder Lug | Panel Mount | 2 | 6 | DP6T | 2 | 9.53 mm | Silver Alloy | 30 V | Adjustable | 115 V | |||
 Grayhill Inc. | 250 mA | Shorting (MBB) | Flatted (3.17mm Dia) | 30 ° | Solder Lug | Panel Mount | 2 | 12 | SP12T | 1 | 9.53 mm | Silver Alloy | 30 V | Adjustable | 115 V | 19.33 mm | 1 | |||
Grayhill Inc. | 250 mA | Non-Shorting (BBM) | Flatted (3.17mm Dia) | 3 | 30 ° | Solder Lug | Panel Mount | 2 | 12 | SP12T | 1 | 9.53 mm | Silver Alloy | 30 V | Adjustable | 115 V | 30.4 mm | |||
 Grayhill Inc. | 250 mA | Non-Shorting (BBM) | Flatted (3.17mm Dia) | 30 ° | Solder Lug | Panel Mount | 2 | 12 | SP12T | 1 | 9.53 mm | Silver Alloy | 30 V | Adjustable | 115 V | 19.33 mm | 1 | |||
Grayhill Inc. | 250 mA | Shorting (MBB) | Flatted (3.17mm Dia) | 3 | 30 ° | Solder Lug | Panel Mount | 2 | 12 | SP12T | 1 | 9.53 mm | Silver Alloy | 30 V | Adjustable | 115 V | 30.4 mm |
