PNP, SOT-23, -45V -100mA, General Purpose Transistor for Automotive
PNP, SOT-23, -45V -100mA, General Purpose Transistor for Automotive
PNP, SOT-23, -45V -100mA, General Purpose Transistor for Automotive
| Part | Voltage - Collector Emitter Breakdown (Max) [Max] | DC Current Gain (hFE) (Min) @ Ic, Vce [Min] | Operating Temperature | Mounting Type | Frequency - Transition | Vce Saturation (Max) @ Ib, Ic | Package / Case | Current - Collector Cutoff (Max) [Max] | Power - Max [Max] | Transistor Type | Supplier Device Package | Current - Collector (Ic) (Max) [Max] | Grade | Qualification |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Rohm Semiconductor | 45 V | 210 | 150 °C | Surface Mount | 250 MHz | 0.65 V | SC-59 SOT-23-3 TO-236-3 | 15 nA | 350 mW | PNP | SST3 | 100 mA | ||
Rohm Semiconductor | 45 V | 210 | 150 °C | Surface Mount | 250 MHz | 0.65 V | SC-59 SOT-23-3 TO-236-3 | 15 nA | 200 mW | PNP | SST3 | 100 mA | Automotive | AEC-Q101 |
