PQ2614BHA Series
Manufacturer: Bourns Inc.
Beta
⌘K
FIXED IND 4.7UH 30A 1.9 MOHM SMD
| Part | Mounting Type | Package / Case | Type | Material - Core | Shielding | DC Resistance (DCR) [Max] | Current Rating (Amps) | Operating Temperature [Min] | Operating Temperature [Max] | Current - Saturation (Isat) | Inductance | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [y] | Ratings | Frequency - Self Resonant | Inductance Frequency - Test | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Tolerance |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Bourns Inc. | Surface Mount | Nonstandard | Drum Core Wirewound | Ferrite | Shielded | 1.9 mOhm | 30 A | -40 C | 155 C | 48 A | 4.7 ÁH | 1.098 " | 0.78 in | 27.9 mm | 19.8 mm | AEC-Q200 | 25 MHz | 100 kHz | 16 mm | 0.63 in | 10 % |
Bourns Inc. | Surface Mount | Nonstandard | Drum Core Wirewound | Ferrite | Shielded | 1.9 mOhm | 30 A | -40 C | 155 C | 5.1 A | 33 µH | 1.098 " | 0.78 in | 27.9 mm | 19.8 mm | AEC-Q200 | 8 MHz | 100 kHz | 16 mm | 0.63 in | 10 % |
Bourns Inc. | Surface Mount | Nonstandard | Drum Core Wirewound | Ferrite | Shielded | 1.9 mOhm | 30 A | -40 C | 155 C | 66.9 A | 3.3 µH | 1.098 " | 0.78 in | 27.9 mm | 19.8 mm | AEC-Q200 | 30 MHz | 100 kHz | 16 mm | 0.63 in | 10 % |
