831810 Series
Manufacturer: Crouzet
Beta
⌘K
SWITCH SNAP ACTION SPDT 6A 250V
| Part | Overtravel [custom] | Overtravel [custom] | Operating Position | Operating Position | Current Rating (Amps) | Differential Travel | Differential Travel | Voltage Rating - DC | Actuator Type | Operating Temperature [Max] | Operating Temperature [Min] | Ingress Protection | Circuit | Operating Force | Release Force | Mounting Type | Switch Function | Mechanical Life | Termination Style | Voltage Rating - AC |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Crouzet | 2.4 mm | 0.094 " | 11.1 mm | 0.437 " | 6 A | 0.016 in | 0.4 mm | 24 V | Lever Straight | 125 °C | -40 C | IP67 - Dust Tight Waterproof | SPDT | 64 gf | 20 gf | Chassis Mount | On-Mom | 2000000 Cycles | Quick Connect - 0.110" (2.8mm) | 250 V |
