PLC3G Series

Catalog

CIRCULAR

...

Part	Mounting Type	Ingress Protection	Material Flammability Rating	Contact Finish - Mating	Backshell Material, Plating	Shell Material	Features	Current Rating (Amps)	Primary Material	Applications	Connector Type	Color	Insert Material	Operating Temperature [Max]	Operating Temperature [Min]	Contact Material	Contact Finish Thickness - Mating	Contact Finish Thickness - Mating	Cable Opening [Max]	Cable Opening [Min]	Cable Opening [Max]	Cable Opening [Min]	Shielding	Orientation	Fastening Type	Cable Opening	Orientation [custom]	Number of Positions	Cable Opening [Max]
ITT Cannon, LLC PLC3G823E03	Free Hanging (In-Line)	IP50 - Dust Protected	UL94 V-0	Gold	Polysulfone (PSU)	Polysulfone (PSU)	Backshell	10 A	Plastic	Industrial Medical Testing Equipment & Measurement	Receptacle Female Sockets	Gray	Plastic	150 °C	-50 °C	Copper Alloy	0.51 µm	20 µin	6.5 mm	0.209 in	0.256 in	5.3 mm	Unshielded	E	Latch Lock Push-Pull
ITT Cannon, LLC PLC3G822J03	Free Hanging (In-Line)	IP50 - Dust Protected	UL94 V-0	Gold	Polysulfone (PSU)	Polysulfone (PSU)	Backshell	10 A	Plastic	Industrial Medical Testing Equipment & Measurement	Receptacle Female Sockets	Gray	Plastic	150 °C	-50 °C	Copper Alloy	0.51 µm	20 µin		0.157 in	0.205 in		Unshielded		Latch Lock Push-Pull	4 mm 5.2 mm	J
ITT Cannon, LLC PLC3G822E06	Free Hanging (In-Line)	IP50 - Dust Protected	UL94 V-0	Gold	Polysulfone (PSU)	Polysulfone (PSU)	Backshell	6 A	Plastic	Industrial Medical Testing Equipment & Measurement	Receptacle Female Sockets	Gray	Plastic	150 °C	-50 °C	Copper Alloy	0.51 µm	20 µin		0.157 in	0.205 in		Unshielded	E	Latch Lock Push-Pull	4 mm 5.2 mm		6
ITT Cannon, LLC PLC3G822C05	Free Hanging (In-Line)	IP50 - Dust Protected	UL94 V-0	Gold	Polysulfone (PSU)	Polysulfone (PSU)	Backshell	7 A	Plastic	Industrial Medical Testing Equipment & Measurement	Receptacle Female Sockets	Gray	Plastic	150 °C	-50 °C	Copper Alloy	0.51 µm	20 µin		0.157 in	0.205 in		Unshielded	C	Latch Lock Push-Pull	4 mm 5.2 mm		5
ITT Cannon, LLC PLC3G822A04	Free Hanging (In-Line)	IP50 - Dust Protected	UL94 V-0	Gold	Polysulfone (PSU)	Polysulfone (PSU)	Backshell	8 A	Plastic	Industrial Medical Testing Equipment & Measurement	Receptacle Female Sockets	Gray	Plastic	150 °C	-50 °C	Copper Alloy	0.51 µm	20 µin		0.157 in	0.205 in		Unshielded	A	Latch Lock Push-Pull	4 mm 5.2 mm		4
ITT Cannon, LLC PLC3G822E02	Free Hanging (In-Line)	IP50 - Dust Protected	UL94 V-0	Gold	Polysulfone (PSU)	Polysulfone (PSU)	Backshell	10 A	Plastic	Industrial Medical Testing Equipment & Measurement	Receptacle Female Sockets	Gray	Plastic	150 °C	-50 °C	Copper Alloy	0.51 µm	20 µin		0.157 in	0.205 in		Unshielded	E	Latch Lock Push-Pull	4 mm 5.2 mm		2
ITT Cannon, LLC PLC3G822E04	Free Hanging (In-Line)	IP50 - Dust Protected	UL94 V-0	Gold	Polysulfone (PSU)	Polysulfone (PSU)	Backshell	8 A	Plastic	Industrial Medical Testing Equipment & Measurement	Receptacle Female Sockets	Gray	Plastic	150 °C	-50 °C	Copper Alloy	0.51 µm	20 µin		0.157 in	0.205 in		Unshielded	E	Latch Lock Push-Pull	4 mm 5.2 mm		4
ITT Cannon, LLC PLC3G823A02	Free Hanging (In-Line)	IP50 - Dust Protected	UL94 V-0	Gold	Polysulfone (PSU)	Polysulfone (PSU)	Backshell	10 A	Plastic	Industrial Medical Testing Equipment & Measurement	Receptacle Female Sockets	Gray	Plastic	150 °C	-50 °C	Copper Alloy	0.51 µm	20 µin	6.5 mm	0.209 in	0.256 in	5.3 mm	Unshielded	A	Latch Lock Push-Pull			2
ITT Cannon, LLC PLC3G821C02	Free Hanging (In-Line)	IP50 - Dust Protected	UL94 V-0	Gold	Polysulfone (PSU)	Polysulfone (PSU)	Backshell	10 A	Plastic	Industrial Medical Testing Equipment & Measurement	Receptacle Female Sockets	Gray	Plastic	150 °C	-50 °C	Copper Alloy	0.51 µm	20 µin		0.106 in	0.154 in	2.7 mm	Unshielded	C	Latch Lock Push-Pull			2	3.9 mm
ITT Cannon, LLC PLC3G822H05	Free Hanging (In-Line)	IP50 - Dust Protected	UL94 V-0	Gold	Polysulfone (PSU)	Polysulfone (PSU)	Backshell	7 A	Plastic	Industrial Medical Testing Equipment & Measurement	Receptacle Female Sockets	Gray	Plastic	150 °C	-50 °C	Copper Alloy	0.51 µm	20 µin		0.157 in	0.205 in		Unshielded	H	Latch Lock Push-Pull	4 mm 5.2 mm		5
