29665 Series
Manufacturer: Phoenix Contact
Beta
⌘K
RELAY GEN PURPOSE SPDT 6A 230V
| Part | Coil Resistance | Switching Voltage | Coil Type | Termination Style | Operating Temperature [Max] | Operating Temperature [Min] | Features | Relay Type | Mounting Type | Contact Rating (Current) | Release Time | Coil Current | Contact Form | Operate Time | Contact Material | Coil Voltage | Coil Voltage | Switching Voltage [Max] | Coil Voltage | Coil Voltage |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Phoenix Contact | 71.86 kOhms | 250 VAC 250 VDC | Non Latching | Spring Terminal | 55 °C | -25 °C | Lighted Indicator Socket Included | General Purpose | DIN Rail | 6 A | 15 ms | 3.2 mA | SPDT (1 Form C) | 7 ms | Silver Tin Oxide (AgSnO) | 230 VDC | 230 VAC | |||
 Phoenix Contact | 5217 Ohms | Non Latching | Spring Terminal | 60 °C | -25 °C | Lighted Indicator Socket Included | General Purpose | DIN Rail | 50 mA | 8 ms | 9.2 mA | SPDT (1 Form C) | 5 ms | Gold (Au) Silver (Ag) | 30 VAC 36 VDC | 48 VDC | ||||
Phoenix Contact | 784 Ohms | Non Latching | Spring Terminal | 60 °C | -40 C | Diode Lighted Indicator Socket Included | General Purpose | DIN Rail | 50 mA | 8 ms | 15.3 mA | SPDT (1 Form C) | 5 ms | Gold (Au) Silver Tin Oxide (AgSnO) | 30 VAC 36 VDC | 12 VDC | ||||
 Phoenix Contact | 2.67 kOhms | Non Latching | Spring Terminal | 60 °C | -25 °C | Lighted Indicator Socket Included | General Purpose | DIN Rail | 50 mA | 8 ms | 9 mA | SPDT (1 Form C) | 5 ms | Gold (Au) Silver (Ag) | 30 VAC 36 VDC | 24 VDC | ||||
Phoenix Contact | 34.29 kOhms | Non Latching | Spring Terminal | 55 °C | -25 °C | Lighted Indicator Socket Included | General Purpose | DIN Rail | 50 mA | 15 ms | 3.5 mA | SPDT (1 Form C) | 6 ms | Gold (Au) Silver (Ag) | 30 VAC 36 VDC | 120VAC/DC | ||||
Phoenix Contact | 2.182 kOhms | 250 VAC 250 VDC | Non Latching | Spring Terminal | 60 °C | -40 C | Lighted Indicator Socket Included | General Purpose | DIN Rail | 6 A | 15 ms | 11 mA | SPDT (1 Form C) | 6 ms | Gold (Au) Silver Tin Oxide (AgSnO) | 24 VAC | ||||
Phoenix Contact | 12.5 kOhms | 250 VAC 250 VDC | Non Latching | Spring Terminal | 60 °C | -40 C | Diode Lighted Indicator | General Purpose | DIN Rail | 6 A | 8 ms | 4.8 mA | SPDT (1 Form C) | 5 ms | Silver Tin Oxide (AgSnO) | 60 VDC | ||||
 Phoenix Contact | 34.29 kOhms | 250 VAC 250 VDC | Non Latching | Spring Terminal | 55 °C | -25 °C | Lighted Indicator Socket Included | General Purpose | DIN Rail | 6 A | 15 ms | 3.5 mA | SPDT (1 Form C) | 6 ms | Silver Tin Oxide (AgSnO) | 120VAC/DC |
