10007367 Series
Manufacturer: Amphenol ICC (FCI)
Beta
⌘K
CONN HEADER VERT 10POS 2.54MM
| Part | Insulation Height | Insulation Height | Shrouding | Connector Type | Contact Type | Fastening Type | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Material Flammability Rating | Overall Contact Length | Overall Contact Length | Contact Finish - Mating | Pitch - Mating | Pitch - Mating | Number of Positions | Contact Length - Post | Contact Length - Post | Contact Length - Mating | Contact Length - Mating | Mounting Type | Contact Shape | Contact Material | Termination | Number of Rows [custom] | Number of Positions Loaded | Insulation Color | Row Spacing - Mating [x] | Row Spacing - Mating [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Amphenol ICC (FCI) | 0.1 in | 2.54 mm | Unshrouded | Header | Male Pin | Push-Pull | 0.76 Ám | 30 Áin | UL94 V-0 | 13.34 mm | 0.525 in | Gold GXT™ | 0.1 " | 2.54 mm | 10 | 0.1 in | 2.54 mm | 8.26 mm | 0.325 in | Through Hole | Square | Phosphor Bronze | Solder | 2 | All | Black | 0.1 in | 2.54 mm |
