G51MA7-P Series
Manufacturer: ODU
Beta
⌘K
ODU MEDI-SNAP RECEPT R/A, STY 5,
| Part | Insert Material | Contact Material | Mounting Feature | Shielding | Current Rating (Amps) | Connector Type | Color | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Ingress Protection | Material Flammability Rating | Shell Material | Voltage Rating | Primary Material | Number of Positions | Fastening Type | Applications | Contact Finish - Mating | Orientation | Shell Size - Insert | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Polyetheretherketone (PEEK) | Brass | Bulkhead - Front or Rear Side Nut | Unshielded | 7.5 A | Receptacle Female Sockets | Blue Gray | Solder | 120 °C | -50 °C | IP50 - Dust Protected | UL94 V-0 | Polysulfone (PSU) | 35 V | Plastic | 5 | Detent Lock Push-Pull | Industrial Medical Testing Equipment & Measurement | Gold | A | 1 | Panel Mount Through Hole | |
Polyetheretherketone (PEEK) | Brass | Bulkhead - Front or Rear Side Nut | Unshielded | 4.55 A | Receptacle Female Sockets | 120 °C | -50 °C | IP50 - Dust Protected | Polysulfone (PSU) | Plastic | 6 | Detent Lock Push-Pull | Industrial Medical Military Testing Equipment & Measurement | Gold | A | 1 | Panel Mount | |||||
Polyetheretherketone (PEEK) | Brass | Bulkhead - Front or Rear Side Nut | Unshielded | 7.5 A | Receptacle Female Sockets | Gray Red | Solder | 120 °C | -50 °C | IP50 - Dust Protected | UL94 V-0 | Polysulfone (PSU) | 48 VDC | Plastic | 4 | Detent Lock Push-Pull | Industrial Medical Testing Equipment & Measurement | Gold | A | 1 | Panel Mount Through Hole | |
Polyetheretherketone (PEEK) | Brass | Bulkhead - Front or Rear Side Nut | Unshielded | 14 A | Receptacle Female Sockets | Gray | 120 °C | -50 °C | IP50 - Dust Protected | Polysulfone (PSU) | Plastic | 2 | Detent Lock Push-Pull | Industrial Medical Military Testing Equipment & Measurement | Gold | A | 1 | Panel Mount | ||||
Polyetheretherketone (PEEK) | Brass | Bulkhead - Front or Rear Side Nut | Unshielded | 4.55 A | Receptacle Female Sockets | Gray Red | 120 °C | -50 °C | IP50 - Dust Protected | Polysulfone (PSU) | Plastic | 7 | Detent Lock Push-Pull | Industrial Medical Military Testing Equipment & Measurement | Gold | A | 1 | Panel Mount | ||||
Polyetheretherketone (PEEK) | Brass | Bulkhead - Front or Rear Side Nut | Unshielded | 2.5 A | Receptacle Female Sockets | Gray White | 120 °C | -50 °C | IP50 - Dust Protected | Polysulfone (PSU) | Plastic | 14 | Detent Lock Push-Pull | Industrial Medical Military Testing Equipment & Measurement | Gold | A | 1 | Panel Mount | ||||
Polyetheretherketone (PEEK) | Brass | Bulkhead - Front or Rear Side Nut | Unshielded | 4.55 A | Receptacle Female Sockets | 120 °C | -50 °C | IP50 - Dust Protected | Polysulfone (PSU) | Plastic | 7 | Detent Lock Push-Pull | Industrial Medical Military Testing Equipment & Measurement | Gold | A | 1 | Panel Mount | |||||
Polyetheretherketone (PEEK) | Brass | Bulkhead - Front or Rear Side Nut | Unshielded | 7.5 A | Receptacle Female Sockets | Gray Red | 120 °C | -50 °C | IP50 - Dust Protected | Polysulfone (PSU) | Plastic | 5 | Detent Lock Push-Pull | Industrial Medical Military Testing Equipment & Measurement | Gold | A | 1 | Panel Mount | ||||
Polyetheretherketone (PEEK) | Brass | Bulkhead - Front or Rear Side Nut | Unshielded | 2.5 A | Receptacle Female Sockets | Blue Gray | 120 °C | -50 °C | IP50 - Dust Protected | Polysulfone (PSU) | Plastic | 14 | Detent Lock Push-Pull | Industrial Medical Military Testing Equipment & Measurement | Gold | A | 1 | Panel Mount | ||||
Polyetheretherketone (PEEK) | Brass | Bulkhead - Front or Rear Side Nut | Unshielded | 6 A | Receptacle Female Sockets | Gray Red | Solder | 120 °C | -50 °C | IP50 - Dust Protected | UL94 V-0 | Polysulfone (PSU) | 36 VDC | Plastic | 6 | Detent Lock Push-Pull | Industrial Medical Testing Equipment & Measurement | Gold | A | 1 | Panel Mount Through Hole |
