Isolated DC/DC Converters - Through Hole DC-DC Converter, 3 Watt, Regulated, 4.5-9VDC Input, 12VDC Output
Isolated DC/DC Converters - Through Hole DC-DC Converter, 3 Watt, Regulated, 4.5-9VDC Input, 12VDC Output
Isolated DC/DC Converters - Through Hole DC-DC Converter, 3 Watt, Regulated, 4.5-9VDC Input, 12VDC Output
| Part | Standard Number | Applications | Operating Temperature [Min] | Operating Temperature [Max] | Efficiency | Power (Watts) | Approval Agency | Voltage - Output 2 | Number of Outputs | Voltage - Input (Max) [Max] | Package / Case | Voltage - Output 1 | Voltage - Input (Min) [Min] | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Type | Mounting Type | Voltage - Isolation | Features | Current - Output (Max) | Current - Output (Max) | Current - Output (Max) [Max] | Control Features | Current - Output (Max) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cincon Electronics Co. LTD | 60950-1 | ITE (Commercial) | -40 °C | 85 °C | 85 % | 3 W | CE | -15 V | 2 | 36 V | 8-SIP Module 7 Leads | 15 V | 18 V | 0.36 in | 0.44 in | 0.86 " | 21.8 mm | 9.2 mm | 11.1 mm | Isolated Module | Through Hole | 1.5 kV | Remote On/Off SCP | 100 mA | 100 mA | |||
Cincon Electronics Co. LTD | 60950-1 | ITE (Commercial) | -40 °C | 85 °C | 78 % | 3 W | CE | 1 | 9 V | 8-SIP Module 7 Leads | 5 V | 4.5 V | 0.36 in | 0.44 in | 0.86 " | 21.8 mm | 9.2 mm | 11.1 mm | Isolated Module | Through Hole | 1.5 kV | Remote On/Off SCP | 600 mA | |||||
Cincon Electronics Co. LTD | 60950-1 | ITE (Commercial) | -40 °C | 85 °C | 81 % | 3 W | CE | 1 | 9 V | 8-SIP Module 7 Leads | 15 V | 4.5 V | 0.36 in | 0.44 in | 0.86 " | 21.8 mm | 9.2 mm | 11.1 mm | Isolated Module | Through Hole | 1.5 kV | Remote On/Off SCP | 200 mA | |||||
Cincon Electronics Co. LTD | 60950-1 | ITE (Commercial) | -40 °C | 85 °C | 81 % | 3 W | CE | 1 | 36 V | 8-SIP Module 7 Leads | 5 V | 18 V | 0.36 in | 0.44 in | 0.86 " | 21.8 mm | 9.2 mm | 11.1 mm | Isolated Module | Through Hole | 1.5 kV | Remote On/Off SCP | 600 mA | |||||
 Cincon Electronics Co. LTD | 60950-1 | ITE (Commercial) | -40 °C | 85 °C | 3 W | CE | -5 V | 2 | 18 V | 8-SIP Module 7 Leads | 5 V | 9 V | 0.36 in | 0.44 in | 0.86 " | 21.8 mm | 9.2 mm | 11.1 mm | Isolated Module | Through Hole | 1.5 kV | Remote On/Off | 0.3 A | |||||
 Cincon Electronics Co. LTD | 60950-1 | ITE (Commercial) | -40 °C | 85 °C | 3 W | CE | -5 V | 2 | 75 V | 8-SIP Module 7 Leads | 5 V | 18 V | 0.36 in | 0.44 in | 0.86 " | 21.8 mm | 9.2 mm | 11.1 mm | Isolated Module | Through Hole | 1.5 kV | Remote On/Off SCP UVLO | 0.3 A | Active High Enable | ||||
Cincon Electronics Co. LTD | 60950-1 | ITE (Commercial) | -40 °C | 85 °C | 78 % | 3 W | CE | -5 V | 2 | 9 V | 8-SIP Module 7 Leads | 5 V | 4.5 V | 0.36 in | 0.44 in | 0.86 " | 21.8 mm | 9.2 mm | 11.1 mm | Isolated Module | Through Hole | 1.5 kV | Remote On/Off SCP | 0.3 A | ||||
Cincon Electronics Co. LTD | 60950-1 | ITE (Commercial) | -40 °C | 85 °C | 81 % | 3 W | CE | -12 V | 2 | 9 V | 8-SIP Module 7 Leads | 12 V | 4.5 V | 0.36 in | 0.44 in | 0.86 " | 21.8 mm | 9.2 mm | 11.1 mm | Isolated Module | Through Hole | 1.5 kV | Remote On/Off SCP | 125 mA | ||||
Cincon Electronics Co. LTD | 60950-1 | ITE (Commercial) | -40 °C | 85 °C | 81 % | 3 W | CE | 1 | 75 V | 8-SIP Module 7 Leads | 5 V | 36 V | 0.36 in | 0.44 in | 0.86 " | 21.8 mm | 9.2 mm | 11.1 mm | Isolated Module | Through Hole | 1.5 kV | Remote On/Off SCP | 600 mA | |||||
Cincon Electronics Co. LTD | 60950-1 | ITE (Commercial) | -40 °C | 85 °C | 86 % | 3 W | CE | 1 | 75 V | 8-SIP Module 7 Leads | 15 V | 36 V | 0.36 in | 0.44 in | 0.86 " | 21.8 mm | 9.2 mm | 11.1 mm | Isolated Module | Through Hole | 1.5 kV | Remote On/Off SCP | 200 mA |
