395-044 Series
Manufacturer: EDAC Inc.
Catalog
.100" (2.54MM) PITCH CARD EDGE CONNECTOR ROHS COMPLIANT: YES
...
| Part | Mounting Type | Material - Insulation | Operating Temperature [Min] | Operating Temperature [Max] | Termination | Contact Type | Card Type | Contact Material | Color | Pitch [x] | Pitch [x] | Read Out | Number of Positions | Card Thickness [Min] | Card Thickness [Min] | Card Thickness [Max] | Card Thickness [Max] | Contact Finish Thickness | Contact Finish Thickness | Termination Rows | Number of Rows | Gender | Number of Positions/Bay/Row [custom] | Contact Finish | Flange Feature | Flange Feature | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Through Hole | Polyester Thermoplastic | -40 °C | 105 ░C | Wire Wrap | Cantilever | Non Specified - Dual Edge | Copper Alloy | Black | 2.54 mm | 0.1 in | Dual | 44 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | 2 | 2 | Female | 22 | Gold | ||||||
 EDAC Inc. | Board Edge Straddle Mount | Polyester Thermoplastic | -40 °C | 105 ░C | Solder | Cantilever | Non Specified - Dual Edge | Copper Alloy | Black | 2.54 mm | 0.1 in | Dual | 44 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | 2 | 2 | Female | 22 | Gold | 4-40 Threaded Insert Top Mount Opening | |||||
 EDAC Inc. | Through Hole Right Angle | Polyester Thermoplastic | -40 °C | 105 ░C | Solder | Cantilever | Non Specified - Single Edge | Copper Alloy | Black | 2.54 mm | 0.1 in | Single | 44 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | 1 | 1 | Female | 44 | Gold | Side Mount Opening Unthreaded | 3.25 mm | 0.128 in | |||
 EDAC Inc. | Through Hole | Polyester Thermoplastic | -40 °C | 105 ░C | Solder | Cantilever | Non Specified - Dual Edge | Copper Alloy | Black | 2.54 mm | 0.1 in | Dual | 44 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | 2 | 2 | Female | 22 | Gold | Top Mount Opening Unthreaded | 0.156 in | 3.96 mm | |||
 EDAC Inc. | Through Hole | Polyester Thermoplastic | -40 °C | 105 ░C | Solder | Cantilever | Non Specified - Single Edge | Copper Alloy | Black | 2.54 mm | 0.1 in | Single | 44 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | 1 | 1 | Female | 44 | Gold | 4-40 Flush Mount Threaded Insert Top Opening | Card Guides | ||||
 EDAC Inc. | Through Hole | Polyester Thermoplastic | -40 °C | 105 ░C | Solder | Cantilever | Non Specified - Dual Edge | Copper Alloy | Black | 2.54 mm | 0.1 in | Dual | 44 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | 2 | 2 | Female | 22 | Gold | 4-40 Flush Mount Threaded Insert Top Opening | |||||
 EDAC Inc. | Through Hole | Polyester Thermoplastic | -40 °C | 105 ░C | Solder | Cantilever | Non Specified - Single Edge | Copper Alloy | Black | 2.54 mm | 0.1 in | Single | 44 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | 1 | 1 | Female | 44 | Gold | Flush Mount M3 Threaded Insert Top Opening | |||||
 EDAC Inc. | Through Hole Right Angle | Polyester Thermoplastic | -40 °C | 105 ░C | Solder | Cantilever | Non Specified - Dual Edge | Copper Alloy | Black | 2.54 mm | 0.1 in | Dual | 44 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | 2 | 2 | Female | 22 | Gold | 4-40 Threaded Insert Top Mount Opening | Card Guides | ||||
 EDAC Inc. | Through Hole Right Angle | Polyester Thermoplastic | -40 °C | 105 ░C | Solder | Cantilever | Non Specified - Single Edge | Copper Alloy | Black | 2.54 mm | 0.1 in | Single | 44 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | 1 | 1 | Female | 44 | Gold | 3.25 mm | 0.128 in | ||||
 EDAC Inc. | Through Hole | Polyester Thermoplastic | -40 °C | 105 ░C | Wire Wrap | Cantilever | Non Specified - Dual Edge | Copper Alloy | Black | 2.54 mm | 0.1 in | Dual | 44 | 1.37 mm | 0.054 " | 1.78 mm | 0.07 in | 10 Áin | 0.25 Ám | 2 | 2 | Female | 22 | Gold | Floating Bobbin Top Mount Opening | 0.116 in | 2.95 mm |
